NEW Alternator for JOHN DEERE 850, 950, 1050, 1250, 1450 & 1650 Tractor-Utility; 400-52215, CH10493, SE501365, TY6647, 021000-728, 021000-7280, 021000-7281, 5702100-728; LESTER 14519

$119.99

Email

Specifications

UNIT TYPE Alternator
VOLT 12
AMPS 25
MOUNT HOLE ID 1 M8x1.25
MOUNT HOLE 1 TYPE Threaded
MOUNT HOLE 2 TYPE Unthreaded
MOUNT HOLE ID 3 8.500mm
MOUNT HOLE 3 TYPE Unthreaded
FAN LOCATION External
REGULATOR LOCATION External
TERMINAL ID 2 B+
TERMINAL 2 SIZE M5x0.8
POLARITY Negative
NUMBER OF GROOVES 1
PULLEY TYPE Solid
WARRANTY 1 Year

Part Number & Interchanges

Manufacturer Name  Manufacturer Part #
ARROWHEAD ND021000-7281, ND5702100-728
ATLANTIC QUALITY PARTS 1400-0523
DENSO 021000-728, 021000-7280, 021000-7281, 5702100-728
JOHN DEERE CH10493, SE501365, TY6647
LESTER 14519
LUCAS ELECTRIC A8110

Applications

Part fit

MAKE MODEL ENGINE YEAR
John Deere 850 Yanmar 3T80 Dsl 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988
John Deere 950 Yanmar 3T90-J Dsl 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988
John Deere 1050 Yanmar 3T90 Dsl 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989
John Deere 1250 Yanmar 3T90 Dsl 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989
John Deere 1450 Yanmar 3T90 Dsl 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989
John Deere 1650 Yanmar 3T90 Dsl 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989
John Deere 900HC JD 3-79 Dsl 1986, 1987, 1988, 1989
