NEW Alternator for BMW Applications; 400-40042, 12-31-7-521-178, 12-31-7-525-376, 2542720, 437557, 439560, TG17C015; LESTER 11260
$419.99
Specifications
| UNIT TYPE | Alternator |
| CRITICAL NOTE | BMW Recommends Replacing The Mounting Bolts When Servicing The Alternator With Bolt Kit #12-31-0-392-568 |
| VOLT | 12 |
| AMPS | 170 |
| REGULATOR CLOCK | 11:00 |
| MOUNT HOLE ID 1 | 10mm |
| MOUNT HOLE 1 TYPE | Unthreaded |
| MOUNT HOLE ID 2 | 8mm |
| MOUNT HOLE 2 TYPE | Unthreaded |
| MOUNT HOLE ID 3 | 10mm |
| MOUNT HOLE 3 TYPE | Unthreaded |
| MOUNT HOLE ID 4 | 8mm |
| MOUNT HOLE 4 TYPE | Unthreaded |
| FAN LOCATION | Internal |
| REGULATOR LOCATION | Internal |
| TERMINAL ID 2 | B+ |
| TERMINAL 2 SIZE | M8x1.25 |
| POLARITY | Negative |
| NUMBER OF GROOVES | 6 |
| PULLEY TYPE | Clutch |
| WARRANTY | 1 Year |
| ADD’L INFO | 1-Blade Plug |
WRITE YOUR OWN REVIEW
We appreciate your feedback about our parts, services experience or anything which may help us to serve you better.
[testimonial_view id=”1″]
Part Number & Interchanges
| Manufacturer Name | Manufacturer Part # |
| ARROWHEAD | AVA0103 |
| BMW | 12-31-7-521-178, 12-31-7-525-376 |
| BOSCH | AL9358X |
| J&N ELECTRICAL PRODUCTS | 400-40042 |
| LESTER | 11260 |
| LUCAS ELECTRIC | LRA02969 |
| VALEO | 2542720, 437557, 439560, TG17C015 |
Part fit
| Year | Make | Model | Engine |
|---|---|---|---|
| Year | Make | Model | Engine |
| 2006 | BMW | 330Xi | 3.0L N52 |
| 2006 | BMW | 330i | 3.0L N52 |
| 2006 - 2007 | BMW | 525Xi | 3.0L N52 |
| 2006 - 2007 | BMW | 525i | 3.0L N52 |
| 2006 - 2007 | BMW | 530Xi | 3.0L N52 |
| 2006 - 2007 | BMW | 530i | 3.0L N52 |
