NEW Alternator for MASSEY FERGUSON MF-6235, MF-6245, MF-6255 & OTH Models; 400-40189, 3780634M1, 3780635M1, 6780634M, A13VI243; LESTER 12421
February 3, 2023
New MAHLE Alternator for CASE IH Puma 165, 180, 195 & 210 | NEW HOLLAND T7030, T7040 & T7050 Tractors; MAH-MG30, 87573243, 84141455, AAN5333, AAN5708, AAN8145, IA1198
February 4, 2023
NEW Alternator for CASE IH Puma 165, 180, 195 & 210 | NEW HOLLAND T7030, T7040 & T7050 Tractors; 400-29042, 87573243, 84141455, 11.203.734, 11.203.825, 11.203.882; LESTER 23842
$289.99
Search: Mahle Alternator
Specifications
| UNIT TYPE | Alternator |
| FAMILY | Letrika/MAHLE AAN |
| VOLT | 12 |
| AMPS | 150 |
| ROTATION DIRECTION | Clockwise |
| MOUNT HOLE ID 1 | 10.200mm |
| MOUNT HOLE 1 TYPE | Unthreaded |
| MOUNT HOLE 2 TYPE | Unthreaded |
| MOUNTING EAR THICKNESS | 2.205″ |
| MOUNTING EAR THICKNESS | 56mm |
| MOUNTING EAR 2 THICKNESS | 2.205″ |
| MOUNTING EAR 2 THICKNESS | 56mm |
| FAN LOCATION | Internal |
| REGULATOR LOCATION | Internal |
| TERMINAL ID 2 | B+ |
| TERMINAL 2 SIZE | M8x1.25 |
| POLARITY | Negative |
| NUMBER OF GROOVES | 10 |
| PULLEY TYPE | Solid |
| PULLEY OUTER DIAMETER | 2.559″ |
| PULLEY OUTER DIAMETER | 65mm |
Part Number & Interchanges
| Manufacturer Name | Manufacturer Part # |
| ARROWHEAD | AIA0034, IA1198, MG30, MG694 |
| CASEIH | 87573243 |
| FORD/NEW HOLLAND | 84141455, 87573243 |
| J&N ELECTRICAL PRODUCTS | 400-29042 |
| LESTER | 23842 |
| LETRIKA/ISKRA | 11.203.734, 11.203.825, 11.203.882, 11.204.233, AAN5708, AAN5745, AAN5776, AAN8145, IA 1198 |
| LUCAS ELECTRIC | LRA03330 |
| MAHLE | 11.203.734, 11.203.825, 11.203.882, 11.204.174, 11.204.233, AAN5708, AAN5745, AAN5776, AAN8145, IA1198, MG30, MG694 |
Applications
Part fit
| MAKE | MODEL | ENGINE | YEAR |
| Case/International Harvester | Puma 165 | 6-411 Diese | 2007 – ON |
| Case/International Harvester | Puma 180 | 6-411 Diesel | 2007 – ON |
| Case/International Harvester | Puma 195 | 6-411 Diesel | 2007 – ON |
| Case/International Harvester | Puma 210 | 6-411 Diesel | 2007 – ON |
| New Holland | T7030 | 6.75L 6cyl 165HP Diesel | 2007 – ON |
| New Holland | T7040 | 6.75L 6cyl 180HP Diesel | 2007 – ON |
| New Holland | T7050 | 6.75L 6cyl 195HP Diesel | 2007 – ON |
| New Holland | T7060 | 6.75L 6cyl 210HP Diesel | 2007 – ON |
