October 18, 2019NEW Alternator for CHRYSLER, DODGE & JEEP Applications; 400-48162, 04801477AA, 04801477AG, 4801477AA, 4801477AG, A3TJ2581; LESTER 11228
$339.15
Specifications
UNIT TYPE | Alternator |
VOLT | 12 |
AMPS | 140 |
REGULATOR CLOCK | 9:00 |
ROTATION DIRECTION | Clockwise |
MOUNT HOLE ID 1 | 11.200mm |
MOUNT HOLE 1 TYPE | Unthreaded |
MOUNT HOLE 2 TYPE | Unthreaded |
MOUNT HOLE ID 3 | 10.200mm |
MOUNT HOLE 3 TYPE | Unthreaded |
MOUNTING EAR THICKNESS | 0.724″ |
MOUNTING EAR THICKNESS | 18.400mm |
MOUNTING EAR 2 THICKNESS | 0.512″ |
MOUNTING EAR 2 THICKNESS | 13mm |
MOUNTING EAR 3 THICKNESS | 0.787″ |
MOUNTING EAR 3 THICKNESS | 20mm |
FAN LOCATION | Internal |
REGULATOR LOCATION | External |
TERMINAL ID 2 | B+ |
TERMINAL 2 SIZE | M8x1.25 |
TERMINAL ID 3 | F1 |
TERMINAL 3 SIZE | Spade |
TERMINAL ID 4 | S |
TERMINAL 4 SIZE | Spade |
POLARITY | Negative |
NUMBER OF GROOVES | 6 |
PULLEY TYPE | Decoupler |
PULLEY OUTER DIAMETER | 2.244″ |
PULLEY OUTER DIAMETER | 57mm |
WARRANTY | 1 Year |
WRITE YOUR OWN REVIEW
We appreciate your feedback about our parts, services experience or anything which may help us to serve you better.
[testimonial_view id=”1″]
Part Number & Interchanges
Manufacturer Name | Manufacturer Part # |
ARROWHEAD | A3TJ2581, AMT0195 |
BOSCH | AL6464X |
CHRYSLER MOTORS | 04801477AA, 04801477AG, 4801477AA, 4801477AG |
J&N | 400-48162 |
LESTER | 11228 |
LUCAS ELECTRIC | LRA03970 |
MITSUBISHI | A3TJ2581 |
Part fit
Year | Make | Model | Engine |
---|---|---|---|
Year | Make | Model | Engine |
2007 - 2010 | CHRYSLER | SEBRING | 2.4L(148) L4 |
2007 - 2014 | JEEP | COMPASS | 2.0L(122) L4 |
2007 - 2014 | JEEP | COMPASS | 2.4L(144) L4 |
2007 - 2014 | JEEP | PATRIOT | 2.0L(122) L4 |
2007 - 2014 | JEEP | PATRIOT | 2.4L(144) L4 |
2008 - 2009 | DODGE | CALIBER | 2.4L(144) L4 |
2008 - 2014 | DODGE | AVENGER | 2.4L(144) L4 |
2011 - 2014 | CHRYSLER | 200 SERIES | 2.4L(148) L4 |
