NEW Alternator for CRUSADER & PLEASURECRAFT Engines – Marine; 400-12298, 19020608, RA097007B, RA097007L, 18-6288; LESTER 8466

$154.99

Search: 2-V PULLEY
Search: 6-GROOVE PULLEY

Email

Specifications

UNIT TYPE Alternator
FAMILY Delco 7SI
VOLT 12
AMPS 70
REGULATOR CLOCK 12:00
MOUNT HOLE ID 1 M8x1.25
MOUNT HOLE 1 TYPE Threaded
MOUNT HOLE 2 TYPE Unthreaded
MOUNTING EAR 2 THICKNESS 1.969″
MOUNTING EAR 2 THICKNESS 50mm
FAN LOCATION Internal
REGULATOR LOCATION Internal
TERMINAL ID 2 B+
TERMINAL 2 SIZE M6x1.00
POLARITY Negative
WARRANTY 1 Year
ADD’L INFO 1-V PULLEY 66mm OD



Part Number & Interchanges

Manufacturer Name Manufacturer Part #
ARROWHEAD 400-12156, ADR0298, D19020608
DELCO 19020608
DIXIE A-1664
DUBOIS 918466
EMP PARTS 4-6288
J&N ELECTRICAL PRODUCTS 400-12156, 400-12298
INDMAR 575010
LESTER 8466
MALLORY 9-19108
MES MOTORCYCLE & MARINE 3202M
MINNPAR 47-1587
MPA SMALL MOTOR P441N
NAPA SMALL MOTOR RN8466
PLEASURECRAFT RA097007B, RA097007L
REMY SMALL MOTOR RA00104
SIERRA MARINE 18-6288
WAI 1-2484-01DR
WAI 8466N-1G
WAI (OLD) 1-2484-01DR
WILSON 90-01-4407
WILSON SMALL ENGINE 70-01-8466

Part fit

Year Make Model Engine
Year Make Model Engine
2002 - 2003 CRUSADER 5.7 8 Cyl. 305CI 5.0L
2002 - 2004 CRUSADER 5 8 Cyl. 305CI 5.0L
2002 - 2005 PLEASURECRAFT 305CI 5.0L 8 Cyl. 305CI 5.0L
2002 - 2005 PLEASURECRAFT 350CI 5.7L 8 Cyl. 350CI 5.7L
2004 CRUSADER 5.7 8 Cyl. 350CI 5.7L
