New SCOTT/IMPERIAL ELECTRIC Reel Motor for Hose Reel & Fire Truck Applications; SCO-P56SX243, 9915.0009, P56SX043, P56SX243
$244.99
Search: 12V 105A Alt
Search: 12V 110A Alt
Specifications
| UNIT TYPE | Alternator |
| VOLT | 12 |
| AMPS | 120 |
| REGULATOR CLOCK | 10:00 |
| ROTATION DIRECTION | Clockwise |
| MOUNT HOLE ID 1 | 8.500mm |
| MOUNT HOLE 1 TYPE | Unthreaded |
| MOUNT HOLE 2 TYPE | Slotted |
| MOUNT HOLE ID 3 | 10.300mm |
| MOUNT HOLE 3 TYPE | Unthreaded |
| MOUNTING EAR THICKNESS | 3.228″ |
| MOUNTING EAR THICKNESS | 82mm |
| MOUNTING EAR 2 THICKNESS | 100mm |
| MOUNTING EAR 2 THICKNESS | 3.937″ |
| MOUNTING EAR 3 THICKNESS | 100mm |
| MOUNTING EAR 3 THICKNESS | 3.937″ |
| FAN LOCATION | Internal |
| REGULATOR LOCATION | Internal |
| TERMINAL ID 2 | B+ |
| TERMINAL 2 SIZE | M8x1.25 |
| TERMINAL ID 3 | L |
| TERMINAL 3 SIZE | Spade |
| TERMINAL ID 4 | DFM |
| TERMINAL 4 SIZE | Spade |
| POLARITY | Negative |
| NUMBER OF GROOVES | 6 |
| PULLEY TYPE | Solid |
| PULLEY OUTER DIAMETER | 2.047″ |
| PULLEY OUTER DIAMETER | 52mm |
| WARRANTY | 1 Year |
