New HIGH OUTPUT Alternator for FORD, MERCURY & LINCOLN Applications; 400-14173, AL7618X, 3W1U10300AA, 3W1U-10300-AA, 3W1U10300AB; LESTER 8313
$219.99
SEARCH: 4G 12V 130A Alt | SEARCH: 6G 12V 135A Alt
Specifications
| UNIT TYPE | Alternator |
| FAMILY | Ford 4G |
| VOLT | 12 |
| AMPS | 200 |
| REGULATOR CLOCK | 1:00 |
| QUALITY TYPE | High Output |
| FAN LOCATION | Internal |
| REGULATOR LOCATION | Internal |
| TERMINAL ID 2 | B+ |
| TERMINAL 2 SIZE | M6x1.00 |
| TERMINAL ID 3 | L |
| TERMINAL 3 SIZE | Spade |
| TERMINAL ID 4 | RC |
| TERMINAL 4 SIZE | Spade |
| TERMINAL ID 5 | S |
| TERMINAL 5 SIZE | Spade |
| POLARITY | Negative |
| NUMBER OF GROOVES | 6 |
| GROOVE OD | 2.319″ |
| GROOVE OD | 58.900mm |
| PULLEY TYPE | Solid |
| PULLEY OUTER DIAMETER | 2.500″ |
| PULLEY OUTER DIAMETER | 63.500mm |
| WARRANTY | 1 Year |
| ADD’L INFO | PCM Controlled Regulator |
