NEW Starter c/w START-STOP System for FORD Edge, Focus & LINCOLN MKC, MKX Auto & Light Trucks; 410-24371, DS7T11000GA, DS7Z11002J, F1FT11000NA, F1FT11000NB, SA1045; LESTER31251
$159.99
Specifications
| UNIT TYPE | Starter |
| ELECTRIC STARTER TYPE | Permanent Magnet Gear Reduction (PMGR) |
| START STOP SYSTEM COMPATIBLE | TRUE |
| POWER | 1.100 kw |
| HP | 1.475 |
| CONDITION | New |
| ROTATION DIRECTION | Clockwise |
| NUMBER OF TEETH | 11 |
| GEAR OD | 1.358″ |
| GEAR OD | 34.500mm |
| LENGTH | 218.800 mm |
| LENGTH | 8.614″ |
| MOUNT HOLE ID 1 | 10.500mm |
| MOUNT HOLE 1 TYPE | Unthreaded |
| MOUNT HOLE 2 TYPE | Unthreaded |
| MOUNTING EAR DISTANCE 1 | 3.799″ |
| MOUNTING EAR DISTANCE 1 | 96.500mm |
| WARRANTY | 1 Year |
| ADD’L INFO | M8-1.25 B+ And motor Studs, M6-1.0 Threaded Post S Terminal |
Part Number & Interchanges
| Manufacturer Name | Manufacturer Part # |
| ARROWHEAD | 410-24371 |
| BOSCH | 0001172404, 0001172405, 0001172410, 0001172411, SR7619N |
| FORD | DS7T11000GA, DS7Z11002J, F1FT11000NA, F1FT11000NB, SA1045 |
| LESTER | 31251 |
| LUCAS ELECTRIC | LRS03796 |
Part fit
| Year | Make | Model | Engine |
|---|---|---|---|
| Year | Make | Model | Engine |
| 2015 - 2016 | LINCOLN | MKZ | 2.0L(122) L4 Turb |
| 2015 - 2019 | FORD | EDGE | 2.0L(122) L4 Turb |
| 2016 - 2018 | FORD | FOCUS | 2.3L Turb |
| 2017 - 2019 | LINCOLN | MKC | 2.3L(140) L4 Turb |
