Specifications
| Unit Type |
Starter |
| Part Type |
Permanent Magnet Direct Drive (PMDD) |
| Voltage |
12 |
| Rotation |
Counter Clockwise |
| Teeth |
10 |
| GEAR OD |
1.248″/ 31.700mm |
| MOUNT HOLE ID 1 |
8mm |
| MOUNT HOLE 1 & 2 TYPE |
Unthreaded |
| Field Housing Length |
3.46″ / 88mm |
WRITE YOUR OWN REVIEW
We appreciate your feedback about our parts, services experience or anything which may help us to serve you better.
[testimonial_view id=”1″]
Part Number & Interchanges
| Manufacturer Name |
Manufacturer Part # |
| ARROWHEAD |
SAB0104 |
| J & N |
410-21062 |
| EMP |
4-5631 |
| OMC OUTBOARD MARINE CORP |
0584818, 0586277, 584818, 586277 |
| SIERRA MARINE |
18-5631 |
| UNITED TECHNOLOGIES |
5711640, SM57116 |
Applications
| MAKE |
MODEL |
YEAR |
ENGINE |
| EVINRUDE JOHNSON |
BE25ARE |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
BE25ARL |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
BE25KE |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
BE25KL |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
BE25QL |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
E25KL |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
E25PL |
1999 |
25HP |
| EVINRUDE JOHNSON |
E25QL |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
E25RE |
1998 – 1999 |
25HP |
| EVINRUDE JOHNSON |
E25RL |
1998 – 1999 |
25HP |
| EVINRUDE JOHNSON |
E25RME |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
E25RML |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
E25TKE |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
E25TKL |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
BJ25ARE |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
BJ25ARL |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
BJ25KE |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
BJ25KL |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
BJ25PL |
1999 – 2001 |
25HP |
| EVINRUDE JOHNSON |
BJ25QL |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
BJ25VL |
2001 |
25HP |
| EVINRUDE JOHNSON |
J25KL |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
J25PL |
1999 – 2001 |
25HP |
| EVINRUDE JOHNSON |
J25QL |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
J25RE |
1998 – 1999 |
25HP |
| EVINRUDE JOHNSON |
J25RL |
1998 – 2001 |
25HP |
| EVINRUDE JOHNSON |
J25RME |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
J25RML |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
J25RVL |
2001 |
25HP |
| EVINRUDE JOHNSON |
J25TEL3 |
1999 – 2001 |
25HP |
| EVINRUDE JOHNSON |
J25TKE |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
J25TKL |
1996 – 1998 |
25HP |
| EVINRUDE JOHNSON |
J25TVL3 |
2001 |
25HP |
| EVINRUDE JOHNSON |
J25VL |
2001 |
25HP |
| EVINRUDE JOHNSON |
BE35ARE |
1996 – 1999 |
35HP |
| EVINRUDE JOHNSON |
BE35ARL |
1996 – 1998 |
35HP |
| EVINRUDE JOHNSON |
BE35ARS |
2000 – 2001 |
35HP |
| EVINRUDE JOHNSON |
BE35KE |
1996 – 1999 |
35HP |
| EVINRUDE JOHNSON |
BE35KL |
1996 – 1998 |
35HP |
| EVINRUDE JOHNSON |
BE35KS |
2000 – 2001 |
35HP |
| EVINRUDE JOHNSON |
BE35QL |
1996 – 1998 |
35HP |
| EVINRUDE JOHNSON |
E35KL |
1996 – 1998 |
35HP |
| EVINRUDE JOHNSON |
E35QL |
1996 – 1998 |
35HP |
| EVINRUDE JOHNSON |
E35RML |
1996 – 1997 |
35HP |
| EVINRUDE JOHNSON |
E35TKL |
1996 – 1998 |
35HP |
| EVINRUDE JOHNSON |
HE35RML |
1996 – 1997 |
35HP |
| EVINRUDE JOHNSON |
BJ35ARE |
1996 – 1999 |
35HP |
| EVINRUDE JOHNSON |
BJ35ARL |
1996 – 1998 |
35HP |
| EVINRUDE JOHNSON |
BJ35EL |
1999 – 2001 |
35HP |
| EVINRUDE JOHNSON |
BJ35EVL |
2001 |
35HP |
| EVINRUDE JOHNSON |
BJ35KE |
1996 – 1999 |
35HP |
| EVINRUDE JOHNSON |
BJ35KL |
1996 – 1998 |
35HP |
| EVINRUDE JOHNSON |
BJ35PL |
1999 – 2001 |
35HP |
| EVINRUDE JOHNSON |
BJ35QL |
1996 – 1998 |
35HP |
| EVINRUDE JOHNSON |
BJ35VL |
2001 |
35HP |
| EVINRUDE JOHNSON |
HJ35RML |
1996 – 1997 |
35HP |
| EVINRUDE JOHNSON |
J35EL |
1999 |
35HP |
| EVINRUDE JOHNSON |
J35KL |
1996 – 1998 |
35HP |
| EVINRUDE JOHNSON |
J35PL |
1999 – 2001 |
35HP |
| EVINRUDE JOHNSON |
J35QL |
1996 – 1998 |
35HP |
| EVINRUDE JOHNSON |
J35RL |
1999 – 2001 |
35HP |
| EVINRUDE JOHNSON |
J35RML |
1996 – 1997 |
35HP |
| EVINRUDE JOHNSON |
J35RVL |
2001 |
35HP |
| EVINRUDE JOHNSON |
J35TEL |
1999 – 2001 |
35HP |
| EVINRUDE JOHNSON |
J35TKL |
1996 |
35HP |
| EVINRUDE JOHNSON |
J35TVL |
2001 |
35HP |
| EVINRUDE JOHNSON |
J35VL |
2001 |
35HP |
