NEW Starter for Hammerhead GT 250, GTS 250, Supersport 250 & OTH Applications; 410-58008, 32545-C29-25, 0110-093000, 172MM-093000; LESTER 19577
$99.99
SEARCH: 486382 (ALSO SAME)
Specifications
| UNIT TYPE | Starter |
| ELECTRIC STARTER TYPE | Permanent Magnet Direct Drive (PMDD) |
| VOLT | 12 |
| ROTATION DIRECTION | Clockwise |
| NUMBER OF TEETH | 9 |
| GEAR OD | 0.449″ |
| GEAR OD | 11.400mm |
| MOUNT HOLE ID 1 | 7mm |
| MOUNT HOLE 1 TYPE | Unthreaded |
| MOUNT HOLE 2 TYPE | Unthreaded |
| WARRANTY | 1 Year |
| 141.5mm Overall Length |
Part Number & Interchanges
| Manufacturer Part # | Manufacturer Name |
| SMU0228 | ARROWHEAD |
| 410-54051 | J & N |
| 18597 | LESTER |
| 22-18597 | BBB SMALL MOTOR |
| 215547 | HI LEVEL |
| 31200-KS4-018 | HONDA |
| 57-2743 | MINNPAR |
| P645N | MPA SMALL MOTOR |
| RN18597 | NAPA SMALL MOTOR |
| RS41228 | REMY SMALL MOTOR |
| 495793 | TUCKER ROCKY |
| 49-5793 | TUCKER ROCKY |
| 71-26-18597 | WILSON SMALL ENGINE |
Applications
Part fit
| MAKE | MODEL | ENGINE | YEAR |
| Baja | WD 250 U Wilderness Trail | ||
| BMS | Go Kart 250cc | ||
| BMS | Go Kart | 250cc, 250cc | |
| BMS | Machoman 250 | ||
| BMS | Power Buggy | 250cc | |
| BMS | Teamguys 250 | ||
| CF-Moto | CF 250T-3 V3 | 2007, 2008, 2009, 2010, 2011 | |
| CF-Moto | CF 250T-5 V5 | 2007, 2008, 2009, 2010, 2011 | |
| CF-Moto | Cruz 250 | 2012, 2013 | |
| CF-Moto | Fashion 250 | 2007, 2008, 2009, 2010, 2011 | |
| Eagle | Tonga 110 Big Wheel | ||
| Eagle | Touring 250 | ||
| Eagle | Touring 250 | 230cc | |
| Go Scoot | Cougar 250 | ||
| Go Scoot | Dingo 250 | ||
| Go Scoot | Falcon 250 | ||
| Hammerhead | GT 250 | ||
| Hammerhead | GTS 250 | ||
| Hammerhead | Supersport 250 | ||
| Honda | CH 250 Elite | 1985, 1986, 1987, 1988 | |
| Honda | CN 250 Helix | 1986, 1987, 1988, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007 | |
| Kazuma | Cougar 250 | ||
| Kazuma | Dingo 250 | ||
| Kazuma | Falcon 250 | ||
| Redcat | DX-250 | ||
| Redcat | FX-250 |
