New MAHLE Starter for HINO FE2618, FF3020, SG5523 & OTH Diesel Engines, JOHN DEERE 1085, 4455 Applications, MERCRUISER EH700 MIE 175/220 HP Engines; MAH-MS365, 410-52110, 10461626, [DENSO 028000-3290, 028000-3291, 028000-3292, 9702800-329]
September 23, 2022NEW Starter for HINO FE2618, FF3020, SG5523 & OTH Diesel Engines, JOHN DEERE 1085, 4455 Applications, MERCRUISER EH700 MIE 175/220 HP Engines; 410-52110, 50-831002050, 28100-2050, 28100-2051, [DENSO 128000-591, 128000-5911, 128000-5912, …]; LESTER 18177
$314.99
Search: MAHLE Starter
Specifications
UNIT TYPE | Starter |
FAMILY | Denso IIF |
VOLT | 12 |
POWER | 4 kw |
HP | 5.364 |
ROTATION DIRECTION | Clockwise |
ELECTRIC STARTER TYPE | Direct Drive (DD) |
NUMBER OF TEETH | 11 |
GEAR OD | 1.654″ |
GEAR OD | 42mm |
LENGTH | 11.299″ |
LENGTH | 287 mm |
MOUNT HOLE ID 1 | 10mm |
MOUNT HOLE 1 TYPE | Unthreaded |
MOUNT HOLE 2 TYPE | Unthreaded |
MOUNT HOLE ID 3 | 10mm |
MOUNT HOLE 3 TYPE | Unthreaded |
REGISTRY OD | 3.504″ |
REGISTRY OD | 89mm |
WARRANTY | 1 Year |
ADD’L INFO | Bolt Hole Center to Center 90mm, Replaces 10-Tooth Version |
WRITE YOUR OWN REVIEW
We appreciate your feedback about our parts, services experience or anything which may help us to serve you better.
[testimonial_view id=”1″]
Part Number & Interchanges
Manufacturer Name | Manufacturer Part # |
ARROWHEAD | SND0238 |
DENSO | 128000-591, 128000-5910, 128000-5911, 128000-5912, 128000-5913, 128000-7570, 128000-7571, 128000-7572, 128000-7573, 9712809-591, 9712809-757 |
HINO | 28100-2050, 28100-2050A, 28100-2050B, 28100-2051A, 28100-2052, 28100-2052B, 28100-2120, 28100-2120A, 28100-2121, 28100-2121B, 28100-2280B |
LESTER | 18177 |
LUCAS ELECTRIC | S9947 |
MAHLE | 11.130.663, AZJ3215, AZJ3297, IS0663, MS365 |
MERCURY MARINE | 50-831002050, 50-831002051, 50-831002052 |
Applications
Part fit
MAKE | MODEL | ENGINE | YEAR |
Hino | EH700 T | 6cyl 393ci 6.4 | 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997 |
Hino | EH700 | 6400cc, 6.4L/393CI 6-Cyl | 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997 |
Hino | EH700T | 6400cc, 6.4L/393CI 6-Cyl | 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997 |
Hino | FC | 4.0L – W04 | 1988, 1989, 1990 |
Hino | FC | 6.0L – W06 | 1984, 1985, 1986, 1987, 1988 |
Hino | FC | 6.0L – W06 | 1989, 1990 |
Hino | FC | 4000cc, 4L W04D | 1988, 1989, 1990 |
Hino | FC | 6000cc, 6L W06D | 1989, 1990 |
Hino | FD16 | 6.0L – WO6 | 1986, 1987 |
Hino | FD16 | 5759cc, 5.8L/351CI L6 W06E | 1986, 1987 |
Hino | FD17 | 6.8L – HO7 | 1988, 1989, 1990, 1991 |
Hino | FD17 | 6728cc, 6.7L/410CI L6 H07C | 1988, 1989, 1990, 1991 |
Hino | FD20 | 6.5L – HO6C- | 1992 |
Hino | FD20 | 6485cc, 6.5L/396CI L6 H06C-T | 1992 |
Hino | FD2218 (FD5H) | 6.5L – HO6C- | 1993, 1994, 1995, 1996, 1997 |
Hino | FD2218 | 6485cc, 6.5L/396CI L6 H06C-T | 1993, 1994, 1995, 1996, 1997 |
Hino | FD2218LP (FD5H) | 6.5L – HO6C- | 1993, 1994, 1995, 1996, 1997 |
Hino | FD2218LP | 6485cc, 6.5L/396CI L6 H06C-T | 1993, 1994, 1995, 1996, 1997 |
Hino | FD5H | 6500cc, 6.5L HO6C-T | 1993, 1994, 1995, 1996, 1997 |
Hino | FE16 | 6.0L – WO6 | 1986, 1987 |
Hino | FE16 | 5759cc, 5.8L/351CI L6 W06E | 1986, 1987 |
Hino | FE17 | 6.8L – HO7 | 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991 |
Hino | FE17 | 6728cc, 6.7L/410CI L6 H07C | 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991 |
Hino | FE19 | 6.5L – HO6C- | 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991 |
Hino | FE19 | 6485cc, 6.5L/396CI L6 H06C-T | 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991 |
Hino | FE20 | 6.5L – HO6C- | 1992 |
Hino | FE20 | 6485cc, 6.5L/396CI L6 H06C-T | 1992 |
Hino | FE2618 (FE5H) | 6.5L – HO6C- | 1993, 1994, 1995, 1996, 1997 |
Hino | FE2618 | 6485cc, 6.5L/396CI L6 H06C-T | 1993, 1994, 1995, 1996, 1997 |
Hino | FE3020 (FE4H) | 6.5L – HO6C- | 1993, 1994, 1995, 1996, 1997 |
Hino | FE3020 | 6500cc, 6.5L HO6C-T | 1993, 1994, 1995, 1996, 1997 |
Hino | FE4H | 6500cc, 6.5L HO6C-T | 1993, 1994, 1995, 1996, 1997 |
Hino | FE5H | 6500cc, 6.5L HO6C-T | 1993, 1994, 1995, 1996, 1997 |
Hino | FF17 | 6.8L – HO7 | 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991 |
Hino | FF17 | 6728cc, 6.7L/410CI L6 H07C | 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991 |
Hino | FF19 | 6.5L – HO6C- | 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991 |
Hino | FF19 | 6485cc, 6.5L/396CI L6 H06C-T | 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991 |
Hino | FF20 | 6.5L – HO6C- | 1992 |
Hino | FF20 | 6485cc, 6.5L/396CI L6 H06C-T | 1992 |
Hino | FF23 | 6.5L – HO6C- | 1992 |
Hino | FF23 | 6485cc, 6.5L/396CI L6 H06C-T | 1992 |
Hino | FF3018 (FF4H) | 6.5L – HO6C- | 1993, 1994, 1995, 1996, 1997 |
Hino | FF3018 | 6485cc, 6.5L/396CI L6 H06C-T | 1993, 1994, 1995, 1996, 1997 |
Hino | FF3020 (FF4H) | 6.5L – HO6C- | 1993, 1994, 1995, 1996, 1997 |
Hino | FF3020 | 6485cc, 6.5L/396CI L6 H06C-T | 1993, 1994, 1995, 1996, 1997 |
Hino | FF4H | 6500cc, 6.5L HO6C-T | 1993, 1994, 1995, 1996, 1997 |
Hino | FG19 | 6.5L – HO6C- | 1984, 1985 |
Hino | FG19 | 6485cc, 6.5L/396CI L6 H06C-T | |
Hino | FG19 | 6485cc, 6.5L/396CI L6 H06C-T | 1985 |
Hino | GC17 | 6.8L – HO7 | 1990, 1991 |
Hino | GC17 | 6728cc, 6.7L/410CI L6 H07C | 1990, 1991 |
Hino | GC20 | 6.5L – HO6C- | 1992 |
Hino | GC20 | 6485cc, 6.5L/396CI L6 H06C-T | 1992 |
Hino | SF17 | 6.8L – HO7 | 1988, 1989, 1990, 1991 |
Hino | SF17 | 6728cc, 6.7L/410CI L6 H07C | 1988, 1989, 1990, 1991 |
Hino | SG19 | 6.5L – HO6C- | 1986, 1987, 1988, 1989, 1990, 1991 |
Hino | SG19 | 6485cc, 6.5L/396CI L6 H06C-T | 1986, 1987, 1988, 1989, 1990, 1991 |
Hino | SG1H | 6500cc, 6.5L HO6C-T | 1993, 1994, 1995, 1996, 1997 |
Hino | SG1HD | 6500cc, 6.5L HO6C-T | 1993, 1994, 1995, 1996, 1997 |
Hino | SG20 | 6.5L – HO6C- | 1992 |
Hino | SG20 | 6485cc, 6.5L/396CI L6 H06C-T | 1992 |
Hino | SG23 | 6.5L – HO6C- | 1987, 1988, 1989, 1990, 1991, 1992 |
Hino | SG23 | 6485cc, 6.5L/396CI L6 H06C-T | 1987, 1988, 1989, 1990, 1991, 1992 |
Hino | SG3320 (SG4H) | 6.5L – HO6C- | 1993, 1994, 1995, 1996, 1997 |
Hino | SG3320 | 6485cc, 6.5L/396CI L6 H06C-T | 1993, 1994, 1995, 1996, 1997 |
Hino | SG3323 (SG1H) | 6.5L – HO6C- | 1993, 1994, 1995, 1996, 1997 |
Hino | SG3323 | 6485cc, 6.5L/396CI L6 H06C-T | 1993, 1994, 1995, 1996, 1997 |
Hino | SG5523 (SG1HD) | 6.5L – HO6C- | 1993, 1994, 1995, 1996, 1997 |
Hino | SG5523 | 6485cc, 6.5L/396CI L6 H06C-T | 1993, 1994, 1995, 1996, 1997 |
John Deere | 1085 | Al | |
John Deere | 2056 | Al | |
John Deere | 2058 | Al | |
John Deere | 2064 | Al | |
John Deere | 2066 | Al | |
John Deere | 4040 | JD 6-404 Ds | 1978, 1979, 1980, 1981, 1982 |
John Deere | 4050 | JD 6-466 Ds | 1983, 1984, 1985, 1986, 1987, 1988 |
John Deere | 4055 | JD 6-466 Ds | 1989, 1990, 1991, 1992 |
John Deere | 410D | 4045 Diese | |
John Deere | 4240 | JD 6-466 Ds | 1978, 1979, 1980, 1981, 1982 |
John Deere | 4250 | JD 6-466 Ds | 1983, 1984, 1985, 1986, 1987, 1988 |
John Deere | 4255 | JD 6-466 Ds | 1989, 1990, 1991, 1992 |
John Deere | 4350 | JD 6-466 Ds | |
John Deere | 4440 | JD 6-466 Ds | 1978, 1979, 1980, 1981, 1982 |
John Deere | 444C | 329 Diese | 1982, 1983, 1984, 1985, 1986 |
John Deere | 444D | 329 Diese | 1987, 1988 |
John Deere | 4450 | JD 6-466 Ds | 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990 |
John Deere | 4455 | JD 6-466 Ds | 1989, 1990, 1991, 1992 |
John Deere | 4455 | Made in Mexic | |
John Deere | 4555 | JD 6-466 Ds | 1989, 1990, 1991, 1992 |
John Deere | 4560 | JD 6-466 Ds | 1992, 1993, 1994 |
John Deere | 4640 | JD 6-466 Ds | 1978, 1979, 1980, 1981, 1982 |
John Deere | 4650 | JD 6-466 Ds | 1983, 1984, 1985, 1986, 1987, 1988 |
John Deere | 4755 | JD 6-466 Ds | 1989, 1990, 1991, 1992 |
John Deere | 4760 | JD 6-466 Ds | 1992, 1993, 1994 |
John Deere | 4840 | JD 6-466 Ds | 1979, 1980, 1981, 1982 |
John Deere | 4850 | JD 6-466 Ds | 1983, 1984, 1985, 1986, 1987, 1988 |
John Deere | 4955 | JD 6-466 Ds | 1989, 1990, 1991, 1992 |
John Deere | 4960 | JD 6-466 Ds | 1992, 1993, 1994 |
John Deere | 500 | Diesel Engine | 1978, 1979, 1980, 1981, 1982, 1983 |
John Deere | 510 | JD 4-269 80HP Ds | 1971, 1972, 1973, 1974, 1975, 1976, 1977, 1978, 1979, 1980, 1981 |
John Deere | 510D | JD 4045T 95HP Ds | |
John Deere | 5200 | 404 Diese | 1974, 1975, 1976, 1977 |
John Deere | 540E | 4045 Diese | |
John Deere | 5420 | Al | |
John Deere | 544 | Al | |
John Deere | 5440 | 404 Diese | 1977, 1978, 1979, 1980, 1981, 1982 |
John Deere | 544C | 414 Diese | 1982, 1983, 1984, 1985, 1986 |
John Deere | 544D | Al | 1987, 1988 |
John Deere | 544E | Al | 1988, 1989, 1990, 1991, 1992 |
John Deere | 544E | Al | 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995 |
John Deere | 544G | 6059 Diese | |
John Deere | 544G | Al | |
John Deere | 570 | 303 Diese | 1975, 1976, 1977, 1978, 1979, 1980, 1981 |
John Deere | 570A | 329 Diese | 1975, 1976, 1977, 1978, 1979, 1980, 1981 |
John Deere | 5720 | 466 Diese | 1982, 1983, 1984, 1985, 1986 |
John Deere | 5730 | 466 Diese | 1986, 1987, 1988, 1989, 1990, 1991, 1992 |
John Deere | 5830 | 466 Diese | 1986, 1987, 1988, 1989, 1990, 1991, 1992 |
John Deere | 6059 | Al | |
John Deere | 6068 | Al | |
John Deere | 6076 | Al | |
John Deere | 624E | Al | 1988, 1989, 1990, 1991, 1992 |
John Deere | 624G | Al | |
John Deere | 640E | 6068 Diese | |
John Deere | 643 | Al | 1988, 1989, 1990, 1991, 1992, 1993 |
John Deere | 643D | Al | |
John Deere | 644C | Al | 1982, 1983, 1984, 1985, 1986 |
John Deere | 644D | Al | 1987, 1988 |
John Deere | 644E | Al | 1988, 1989, 1990, 1991, 1992 |
John Deere | 644G | Al | |
John Deere | 6466A / D / T | Al | |
John Deere | 6600 | 404 Diese | 1979, 1980, 1981, 1982 |
John Deere | 6602 | 404 Diese | 1979, 1980, 1981, 1982 |
John Deere | 6620 | 466 Diese | 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988 |
John Deere | 6622 | 466 Diese | 1980, 1981, 1982, 1983, 1984, 1985 |
John Deere | 690 / 690A | 404 Diese | 1975, 1976, 1977, 1978, 1979, 1980, 1981, 1982, 1983 |
John Deere | 690B | 404 Diese | 1974, 1975, 1976, 1977, 1978, 1979, 1980, 1981, 1982, 1983 |
John Deere | 693B | Al | 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985 |
John Deere | 710D | JD 6059T 115HP Ds | |
John Deere | 740 | 466 Diese | 1974, 1975, 1976, 1977, 1978, 1979 |
John Deere | 740A | 466 Diese | 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988 |
John Deere | 743 | Al | 1977, 1978, 1979, 1980, 1981, 1982, 1983 |
John Deere | 743A | Al | 1977, 1978, 1979, 1980, 1981, 1982, 1983 |
John Deere | 7700 | 404 Diese | 1979, 1980, 1981, 1982 |
John Deere | 7700 | 6-414 Diese | |
John Deere | 7710 | 6-466 Diese | |
John Deere | 7720 | 466 Diese | 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989 |
John Deere | 7722 | 466 Diese | 1986, 1987, 1988, 1989 |
John Deere | 7800 | 6-466 Diese | |
John Deere | 7810 | 6-466 Diese | |
John Deere | 8100 | 6-466 Diese | |
John Deere | 8200 | 6-466 Diese | |
John Deere | 8300 | 6-466 Diese | |
John Deere | 8430 | 6-466 Diese | 1975, 1976, 1977, 1978 |
John Deere | 8440 | 6-466 Diese | 1979, 1980, 1981, 1982 |
John Deere | 8450 | 6-466 Diese | 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989 |
John Deere | 8560 | 6-466 Diese | 1988, 1989, 1990, 1991, 1992 |
John Deere | 8820 | 466 Diese | 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992 |
John Deere | 9500 | 466 Diese | 1989, 1990, 1991, 1992, 1993 |
John Deere | 9600 | 466 Diese | 1989, 1990, 1991, 1992, 1993 |
John Deere | 9650 | 466 Diese | 1989, 1990, 1991, 1992, 1993 |
John Deere | 9940 | 466 Diese | 1983, 1984, 1985, 1986 |
John Deere | 9950 | 466 Diese | 1987, 1988, 1989, 1990 |
John Deere | 9960 | 466 Diese | 1987, 1988, 1989, 1990, 1991, 1992, 1993 |
John Deere | 9965 | 466 Diese | |
John Deere | CTS Combine | Al | 1992, 1993, 1994 |
John Deere | JD444 | 329 Diese | 1976, 1977, 1978, 1979, 1980, 1981 |
John Deere | JD500C | JD 80HP Ds | 1974, 1975, 1976, 1977, 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985 |
John Deere | JD544 / JD544A | 414 Diese | 1976, 1977, 1978, 1979, 1980, 1981 |
John Deere | JD544B | 414 Diese | 1975, 1976, 1977, 1978, 1979, 1980, 1981, 1982 |
Mercruiser | Model EH700 MIE (175 / 220HP) | HINO 6.5L – 393ci – 6cy | 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997 |
Mercruiser | Model EH700 MIE | 6500cc, 175HP 6.5L/393CI 6-Cyl Hino Diesel , Diesel | 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997 |
Mercruiser | Model EH700 MIE | 6500cc, 220HP 6.5L/393CI 6-Cyl Hino Diesel , Diesel | 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997 |
