NEW Starter for HONDA CB 500 F, CBR 500 R & CMX 500 Rebel Motorcycles; 410-54258, 31200-MGZ-J01, 31200MGZ-J01
$159.99
Specifications
| UNIT TYPE |
Starter |
| ELECTRIC STARTER TYPE |
Permanent Magnet Direct Drive (PMDD) |
| VOLT |
12 |
| ROTATION DIRECTION |
Counter Clockwise |
| NUMBER OF TEETH |
9 |
| GEAR OD |
0.472″ |
| GEAR OD |
12mm |
| LENGTH |
119.500 mm |
| LENGTH |
4.705″ |
| MOUNT HOLE ID 1 |
7.100mm |
| MOUNT HOLE 1 TYPE |
Unthreaded |
| MOUNT HOLE 2 TYPE |
Unthreaded |
| MOUNTING EAR DISTANCE 2 |
1.811″ |
| MOUNTING EAR DISTANCE 2 |
46mm |
| REGISTRY OD |
1.181″ |
| REGISTRY OD |
30mm |
| WARRANTY |
1 Year |
| ADD’L INFO |
M6 B+ Stud |
Part Number & Interchanges
| Manufacturer Name |
Manufacturer Part # |
| ARROWHEAD |
SMU0559 |
| HONDA |
31200-MGZ-J01, 31200MGZ-J01 |
| J&N |
410-5425 |
Part fit
| Year |
Make |
Model |
Engine |
| Year |
Make |
Model |
Engine |
| 2013 - 2017 |
HONDA |
CBR 500 R |
471 cc |
| 2013 - 2018 |
HONDA |
CB 500 F |
471 cc |
| 2013 - 2018 |
HONDA |
CB 500 F ABS |
471 cc |
| 2015 - 2018 |
HONDA |
CBR 500 R ABS |
471 cc |
| 2017 - 2018 |
HONDA |
CMX 500 Rebel |
471 cc |
| 2017 - 2018 |
HONDA |
CMX 500 Rebel ABS |
471 cc |
