NEW Starter for HONDA GL1200 Gold Wing Series; 410-54109, 31200-MG9-406, 31200MG9-406, 31200-MG9-681, 31200MG9-681; LESTER 18628
$154.99
Specifications
| UNIT TYPE | Starter |
| ELECTRIC STARTER TYPE | Permanent Magnet Direct Drive (PMDD) |
| VOLT | 12 |
| ROTATION DIRECTION | Clockwise |
| GEAR OD | 0.531″ |
| GEAR OD | 13.500mm |
| MOUNT HOLE ID 1 | 6.800mm |
| MOUNT HOLE 1 TYPE | Unthreaded |
| MOUNT HOLE 2 TYPE | Unthreaded |
| WARRANTY | 1 Year |
| 3 Bolt DE Frame, 2nd Mounting Hole is 6.1mm x 8.1mm Slotted |
Part Number & Interchanges
| Manufacturer Name | Manufacturer Part # |
| ARROWHEAD | SMU0112 |
| HI LEVEL | STH0112 |
| HONDA | 31200-MG9-406, 31200MG9-406, 31200-MG9-681, 31200MG9-681 |
| J&N ELECTRICAL PRODUCTS | 410-54109 |
| LESTER | 18628 |
Applications
| MAKE | MODEL | ENGINE | YEAR |
| HONDA | GL1200 Gold Wing | 1181cc | 1986 |
| HONDA | GL1200A Gold Wing Aspencade | 1181cc | 1985, 1986, 1987 |
| HONDA | GL1200D Gold Wing Deluxe | 1181cc | 1986 |
| HONDA | GL1200I Gold Wing Interstate | 1181cc | 1985, 1986, 1987 |
| HONDA | GL1200L Gold Wing LTD | 1181cc | 1985 |
| HONDA | GL1200SEI Gold Wing Aspencade | 1181cc | 1986 |
