NEW Starter for IVECO FIAT Applications; 410-24343, 0001362102, 106055, 4856055; LESTER 30036
$249.99
Specifications
UNIT TYPE |
Starter |
ELECTRIC STARTER TYPE |
Direct Drive (DD) |
VOLT |
12 |
POWER |
2.400 kw |
HP |
3.218 |
ROTATION DIRECTION |
Clockwise |
NUMBER OF TEETH |
9 |
GEAR OD |
1.331″ |
GEAR OD |
33.800mm |
LENGTH |
223.700 mm |
LENGTH |
8.807″ |
MOUNT HOLE ID 1 |
M10x1.25 |
MOUNT HOLE ID 2 |
M10x1.25 |
MOUNT HOLE 3 TYPE |
Unthreaded |
REGISTRY OD |
110mm |
REGISTRY OD |
4.331″ |
Part Number & Interchanges
Manufacturer Name |
Manufacturer Part # |
ARROWHEAD |
MS335, SBO0359 |
BOSCH |
0001362102, 0-001-362-102 |
DELCO |
DRS1063 |
IVECO |
106055, 4856055 |
J&N ELECTRICAL PRODUCTS |
410-24343 |
LESTER |
30036 |
LETRIKA/ISKRA |
11.130.532, AZJ3156, IS 0532 |
LUCAS ELECTRIC |
LRT00136 |
MAHLE |
MS335 |
MARELLI |
63217410, MT74L |
