$164.99
Specifications
Unit Type | Starter |
Part Type | Offset Gear Reduction (OSGR) |
Voltage | 12 |
Rotation | Clockwise |
NUMBER OF TEETH | 9 |
GEAR OD | 1.327″/ 3.700mm |
POWER | 1.200 kw/ 1.609 HP |
MOUNT HOLE ID 1 | 11mm |
MOUNT HOLE 1 & 2 TYPE | Unthreaded |
WARRANTY | 1 Year |
Part Number & Interchanges
Manufacturer Name | Manufacturer Part # |
ARROWHEAD | SND0324, ND128000-8460, ND9712809-846 |
DENSO | 128000-8460, 128000-8461, 128000-8462, 9712809-846 |
J&N | 410-52182 |
KUBOTA | 34070-16081, 34070-16083, 34070-16800, 34070-16802, 34070-16803 |
Applications
YEAR | MAKE | TYPE | MODEL | ENGINE |
All | KUBOTA | Generator Sets | KJS130D | Kubota D1703 Dsl |
All | KUBOTA | Generator Sets | KJS130DX | Kubota D1703E Dsl |
1990 | KUBOTA | Tractors – Compact | L2550GST | Kubota D1402DIA 29.5HP Dsl |
1990 – 1996 | KUBOTA | Tractors – Compact | L2650DT | Kubota D1402DIAE 29HP Dsl |
1991 – 1993 | KUBOTA | Tractors – Compact | L2650F | Kubota D1402DIAE 29HP Dsl |
1991 – 1993 | KUBOTA | Tractors – Compact | L2650GST | Kubota D1402DIAE 29HP Dsl |
2005 – 2009 | KUBOTA | Tractors – Compact | L2800DT-F | Kubota D1403ME2A 29HP Dsl |
2005 – 2009 | KUBOTA | Tractors – Compact | L2800DT-R | Kubota D1403ME2A 29HP Dsl |
2005 – 2009 | KUBOTA | Tractors – Compact | L2800F-F | Kubota D1403ME2A 29HP Dsl |
2005 – 2009 | KUBOTA | Tractors – Compact | L2800F-R | Kubota D1403ME2A 29HP Dsl |
2005 – 2009 | KUBOTA | Tractors – Compact | L2800HST | Kubota D1403ME2A 29HP Dsl |
1994 – 1998 | KUBOTA | Tractors – Compact | L2900DT | Kubota D1503LA 32HP Dsl |
1994 – 1998 | KUBOTA | Tractors – Compact | L2900DTGST | Kubota D1503LA 32HP Dsl |
1994 – 1998 | KUBOTA | Tractors – Compact | L2900F | Kubota D1503LA 32HP Dsl |
1994 – 1998 | KUBOTA | Tractors – Compact | L2900GST | Kubota D1503LA 32HP Dsl |
1991 – 1993 | KUBOTA | Tractors – Compact | L2950DT | Kubota D1462DIAE 30HP Dsl |
1991 – 1993 | KUBOTA | Tractors – Compact | L2950DTGST | Kubota D1462DIAE 30HP Dsl |
1991 – 1993 | KUBOTA | Tractors – Compact | L2950F | Kubota D1462DIAE 30HP Dsl |
1991 – 1993 | KUBOTA | Tractors – Compact | L2950GST | Kubota D1462DIAE 30HP Dsl |
1998 – 2002 | KUBOTA | Tractors – Compact | L3010DT | Kubota D1503LAN 32HP Dsl |
1998 – 2002 | KUBOTA | Tractors – Compact | L3010F | Kubota D1503LAN 32HP Dsl |
1998 – 2002 | KUBOTA | Tractors – Compact | L3010GST | Kubota D1503LAN 32HP Dsl |
1998 – 2002 | KUBOTA | Tractors – Compact | L3010HST | Kubota D1503LAN 32HP Dsl |
03-On | KUBOTA | Tractors – Compact | L3130DT-F | Kubota D1503MAE-GST 32HP Dsl |
03-On | KUBOTA | Tractors – Compact | L3130DT-R | Kubota D1503MAE-GST 32HP Dsl |
03-On | KUBOTA | Tractors – Compact | L3130F-F | Kubota D1503MAE-GST 32HP Dsl |
03-On | KUBOTA | Tractors – Compact | L3130F-R | Kubota D1503MAE-GST 32HP Dsl |
03-On | KUBOTA | Tractors – Compact | L3130GST-F | Kubota D1503MAE-GST 32HP Dsl |
03-On | KUBOTA | Tractors – Compact | L3130GST-R | Kubota D1503MAE-GST 32HP Dsl |
03-On | KUBOTA | Tractors – Compact | L3130HST-C | Kubota D1503MAE-GST 32HP Dsl |
03-On | KUBOTA | Tractors – Compact | L3130HST-F | Kubota D1503MAE-GST 32HP Dsl |
03-On | KUBOTA | Tractors – Compact | L3130HST-R | Kubota D1503MAE-GST 32HP Dsl |
2007 – 2008 | KUBOTA | Tractors – Compact | L3240F | Kubota D1703-M-E2 34HP Dsl |
2007 – 2008 | KUBOTA | Tractors – Compact | L3240GST | Kubota D1703-M-E2 34HP Dsl |
2007 – 2008 | KUBOTA | Tractors – Compact | L3240HST | Kubota D1703-M-E2 34HP Dsl |
2007 – 2008 | KUBOTA | Tractors – Compact | L3240HSTC | Kubota D1703-M-E2 34HP Dsl |
1994 – 1998 | KUBOTA | Tractors – Compact | L3300DT | Kubota D1703-A 35HP Dsl |
1994 – 1998 | KUBOTA | Tractors – Compact | L3300DTGST | Kubota D1703-A 35HP Dsl |
1994 – 1998 | KUBOTA | Tractors – Compact | L3300F | Kubota D1703-A 35HP Dsl |
1994 – 1998 | KUBOTA | Tractors – Compact | L3300GST | Kubota D1703-A 35HP Dsl |
2005 – 2009 | KUBOTA | Tractors – Compact | L3400DT-F | Kubota D1703MAE2A 34.7HP Dsl |
2005 – 2009 | KUBOTA | Tractors – Compact | L3400DT-R | Kubota D1703MAE2A 34.7HP Dsl |
2005 – 2009 | KUBOTA | Tractors – Compact | L3400F-F | Kubota D1703MAE2A 34.7HP Dsl |
2005 – 2009 | KUBOTA | Tractors – Compact | L3400F-R | Kubota D1703MAE2A 34.7HP Dsl |
2005 – 2009 | KUBOTA | Tractors – Compact | L3400HST | Kubota D1703MAE2A 34.7HP Dsl |
1998 – 2002 | KUBOTA | Tractors – Compact | L3410DT | Kubota D1703A 35.1HP Dsl |
1998 – 2002 | KUBOTA | Tractors – Compact | L3410GST | Kubota D1703A 35.1HP Dsl |
1998 – 2002 | KUBOTA | Tractors – Compact | L3410HST | Kubota D1703A 35.1HP Dsl |
03-On | KUBOTA | Tractors – Compact | L3430DT-F | Kubota D1703MAE 35.1HP Dsl |
03-On | KUBOTA | Tractors – Compact | L3430DT-R | Kubota D1703MAE 35.1HP Dsl |
03-On | KUBOTA | Tractors – Compact | L3430GST-F | Kubota D1703MAE 35.1HP Dsl |
03-On | KUBOTA | Tractors – Compact | L3430GST-R | Kubota D1703MAE 35.1HP Dsl |
03-On | KUBOTA | Tractors – Compact | L3430HST-F | Kubota D1703MAE 35.1HP Dsl |
03-On | KUBOTA | Tractors – Compact | L3430HST-R | Kubota D1703MAE 35.1HP Dsl |
96-On | KUBOTA | Tractors – Compact | L35TL | Kubota D1703TLB 35HP Dsl |
96-On | KUBOTA | Tractors – Compact | L35TLB | Kubota D1703TLB 35HP Dsl |
