NEW Starter for YAMAHA ATV Various Models; 410-54039, SM13528, 4WV81800-00-00, 4WV81890-00-00, 5KM81890-00-0, 5KM-81890-00-00, 5KM81890-00-00; LESTER 18759
October 21, 2023NEW Starter for YAMAHA YFZ 450 ATV Various Models; 410-54145, 18P81890-00-00; LESTER 19200
October 21, 2023NEW Starter for YAMAHA ATV & Motorcycles Various Models; 410-54067, SM13240, 3HE81890-00-00, 3HW81800-00-00; LESTER 18745, 18757
$119.99
Specifications
UNIT TYPE | Starter |
FAMILY | Mitsuba SM13 |
ELECTRIC STARTER TYPE | Permanent Magnet Direct Drive (PMDD) |
VOLT | 12 |
ROTATION DIRECTION | Counter Clockwise |
NUMBER OF TEETH | 9 |
GEAR OD | 0.472″ |
GEAR OD | 12mm |
MOUNT HOLE ID 1 | 6mm |
MOUNT HOLE 1 TYPE | Unthreaded |
MOUNT HOLE 2 TYPE | Unthreaded |
WARRANTY | 1 Year |
Part Number & Interchanges
Manufacturer Name | Manufacturer Part # |
ARROWHEAD | SCH0092, SMU0165, SMU0269 |
HI LEVEL | STY0269 |
HISUN | 31200-003-0000 |
LESTER | 18745, 18757 |
MITSUBA | SM13240 |
SOCIETA GENERALE RICAMBI | 17.8154 |
YAMAHA | 3HE81890-00-00, 3HW81800-00-00 |
Applications
MAKE | MODEL | ENGINE | YEAR |
Coleman | Outfitter 400 | ||
Coleman | Trail Tamer 360 | ||
Hisun | 400 4×4 | ||
Hisun | RX400 | ||
Yamaha | FZR 600 R | 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999 | |
Yamaha | FZR 600 | 1989, 1990, 1991, 1992, 1993 | |
Yamaha | YFM 125 Grizzly | 2004 | |
Yamaha | YFM 300 G Grizzly 2×4 | 2012 | |
Yamaha | YFM 350 A Bruin 2×4 | 2004 | |
Yamaha | YFM 350 BA Bruin 2×4 | 2005, 2006 | |
Yamaha | YFM 350 DH Grizzly 4×4 Hunter | 2014 | |
Yamaha | YFM 350 FA Bruin 4×4 | 2004, 2005, 2006 | |
Yamaha | YFM 350 FG Grizzly 4×4 | 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014 | |
Yamaha | YFM 350 FGH Grizzly 4×4 Hunter | 2008, 2009, 2010, 2011, 2012, 2013 | |
Yamaha | YFM 350 FGI Grizzly IRS 4×4 | 2007, 2008, 2009, 2010, 2011, 2014 | |
Yamaha | YFM 350 FGIH Grizzly IRS 4×4 Hunter | 2007, 2008, 2009, 2010, 2011 | |
Yamaha | YFM 350 G Grizzly 2×4 | 2007, 2008, 2009, 2010, 2011 | |
Yamaha | YFM 350 TE Grizzly 2×4 | 2014 | |
Yamaha | YFM 350 X Wolverine 2×4 | 2006, 2007, 2008, 2009 | |
Yamaha | YZF 600 R Thunder Cat | 1995, 1996, 1997, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007 | |
Yamaha | YZF 600 R | 1995, 1996, 1997, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007 |
