NEW Starter for YAMAHA YFB 250, YFM 200, YTM 200 & YTM 225 ATV Various Models; 410-54016, SM14209, SM7255, SM-7255, 29U81800-61-00, 4BD81800-00-00, 4BD81800-01-00; LESTER 18754

$89.99

Email
Categories: ,

Specifications

UNIT TYPE Starter
FAMILY Mitsuba SM14
ELECTRIC STARTER TYPE Permanent Magnet Direct Drive (PMDD)
VOLT 12
POWER 0.400 kw
HP 12:51
ROTATION DIRECTION Counter Clockwise
NUMBER OF TEETH 9
GEAR OD 0.559″
GEAR OD 14.200mm
LENGTH 176.200 mm
LENGTH 6.937″
MOUNT HOLE ID 1 M6x1.00
MOUNT HOLE 1 TYPE Threaded
MOUNT HOLE ID 2 M6x1.00
MOUNT HOLE 2 TYPE Threaded
REGISTRY OD 1.173″
REGISTRY OD 29.800mm
WARRANTY 1 Year

Part Number & Interchanges

Manufacturer Name Manufacturer Part #
ARROWHEAD SMU0063
HI LEVEL STY0063
J&N ELECTRICAL PRODUCTS 410-54016
LESTER 18754
MITSUBA SM14209, SM7255, SM-7255
OTHER OEMS 4BD81890-00
YAMAHA 29U81800-61-00, 4BD81800-00-00, 4BD81800-01-00, 4BD81800-02-00, 4BD81890-00, 4XE81800-00-00, 4XE81890-00-00

Applications

MAKE MODEL ENGINE YEAR
Yamaha YFB 250 F Timberwolf 2×4 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999
Yamaha YFB 250 FW Timberwolf 4×4 1994, 1995, 1996, 1997, 1998, 1999, 2000
Yamaha YFM 200 Moto-4 1985, 1986, 1987, 1988, 1989, 1990
Yamaha YFM 250 X Beartracker 2×4 1999, 2000, 2001, 2002, 2003, 2004
Yamaha YTM 200 E Tri-Moto 1983, 1984, 1985
Yamaha YTM 200 E Yamahauler 1984
Yamaha YTM 200 EK 1983
Yamaha YTM 200 EL 1984
Yamaha YTM 200 ERN 1985
Yamaha YTM 200 Tri-Moto 1983, 1984, 1985, 1986
Yamaha YTM 225 DX Tri-Moto 1983, 1984, 1985, 1986
Yamaha YTM 225 DXK Tri-Moto 1983, 1984
Yamaha YTM 225 DXL Tri-Moto 1983
Yamaha YTM 225 Tri-Moto 1983, 1984, 1985, 1986
