NEW Winch Motor for SUPERWINCH HUSKEY & WARN WINCH Applications; 430-20018, F000MM0626, F006MM0600, F006MM0601, F006MM0602, MRVB7; LESTER 10746, 10747
June 1, 2020NEW Winch Motor for SUPERWINCH & WARN WINCH Applications; 430-20073, 7682, IM0146, MM293
June 2, 2020NEW Winch Motor for SUPERWINCH HUSKY SERIES & WARN WINCH Applications; 430-20066, 38894, 9130450047, 458058, M-1900, 226626, 9130450047; LESTER 10746HD
$219.99
INFO: wo/OVERLOAD DEVICE, 4.8HP VERSION
SEARCH: DOUBLE BALL BEARING | w/DE FRAME ATTACHED | 6.0HP VERSION
Specifications
UNIT TYPE | Winch Motor |
CURRENT TYPE | DC |
VOLT | 12 |
POWER | 3.579 kw |
HP | 4.800 |
ROTATION DIRECTION | Reversible |
OD | 114.300 mm |
OD | 4.500″ |
SHAFT OD | 0.654″ |
SHAFT OD | 16.600mm |
LENGTH | 232.500 mm |
LENGTH | 9.154″ |
TERMINAL 2 SIZE | M8-1.25 |
TERMINAL 3 SIZE | M8-1.25 |
TERMINAL 4 SIZE | M8-1.25 |
SHAFT | 20 Straight Splines |
WARRANTY | 1 Year |
ADD’L INFO | 165.1mm (6.5″) Long Field Case
SUPERWINCH HUSKY SERIES |
Part Number & Interchanges
Manufacturer Name | Manufacturer Part # |
ARROWHEAD | LRW0013 |
J & N | 430-20066 |
LESTER | 10746HD |
BOSCH | 9130450047 |
EMS | 10746HDN |
MAXON | 226626 |
MTE HYDRAULICS | M-1900 |
RAMSEY WINCH | 458058 |
REFERENCE NUMBER | 7536 |
REFERENCE NUMBER | 11212449 |
REFERENCE NUMBER | D-2000 |
REFERENCE NUMBER | AMJ4635 |
REFERENCE NUMBER | 15877 |
WAI | 10746HDN |
WARN WINCH | 9130450047 |
WARN WINCH | 38894 |
WESTERN MOTORS | W-7623 |
