NEW 3-Wire 10SI Type Alternator for Mercruiser & OMC Marine Applications; 400-12485, 70-01-7152HO, 90-01-3103A; LESTER 7152-105
$179.99
Specifications
| UNIT TYPE | Alternator |
| FAMILY | Delco 10SI |
| FAMILY TYPE | 110 |
| NOTES | 3-Wire System |
| VOLT | 12 |
| AMPS | 105 |
| REGULATOR CLOCK | 12:00 |
| ROTATION DIRECTION | Clockwise |
| MOUNT HOLE ID 1 | 5/16-18 |
| MOUNT HOLE 1 TYPE | Threaded |
| MOUNT HOLE 2 TYPE | Unthreaded |
| MOUNTING EAR THICKNESS | 0.697″ |
| MOUNTING EAR THICKNESS | 17.700mm |
| MOUNTING EAR 2 THICKNESS | 2″ |
| MOUNTING EAR 2 THICKNESS | 50.800mm |
| FAN LOCATION | External |
| REGULATOR LOCATION | Internal |
| TERMINAL ID 2 | B+ |
| TERMINAL 2 SIZE | M6x1.00 |
| POLARITY | Negative |
| NUMBER OF GROOVES | 1 |
| PULLEY TYPE | Solid |
| PULLEY OUTER DIAMETER | 2.390″ |
| PULLEY OUTER DIAMETER | 60.700mm |
| WARRANTY | 1 Year |
Part Number & Interchanges
| Manufacturer Name | Manufacturer Part # |
| ARROWHEAD | ADR0341 |
| J&N | 400-12089, 400-12485 |
| LESTER | 7152-105 |
| WILSON | 70-01-7152HO, 90-01-3103A |
