NEW Regulator / Rectifier for ARCTIC CAT Bearcat 340, Cheetah 340, Jag AFS Deluxe & OTH Snowmobiles; 230-22142, 0109-823, 0232-020, 0630-001
$254.99
Specifications
| UNIT TYPE | Alternator |
| QUALITY TYPE | Standard |
| VOLT | 12 |
| AMPS | 80 |
| REGULATOR CLOCK | 3:00 |
| MOUNT HOLE ID 1 | M8x1.25 |
| MOUNT HOLE 1 TYPE | Threaded |
| MOUNT HOLE 2 TYPE | Unthreaded |
| MOUNT HOLE ID 3 | 8.300mm |
| MOUNT HOLE 3 TYPE | Unthreaded |
| MOUNTING EAR THICKNESS | 0.496″ |
| MOUNTING EAR THICKNESS | 12.600mm |
| MOUNTING EAR 2 THICKNESS | 0.587″ |
| MOUNTING EAR 2 THICKNESS | 14.900mm |
| MOUNTING EAR 3 THICKNESS | 0.630″ |
| MOUNTING EAR 3 THICKNESS | 16mm |
| FAN LOCATION | Internal |
| REGULATOR LOCATION | Internal |
| TERMINAL ID 2 | B+ |
| TERMINAL 2 SIZE | M6x1.00 |
| TERMINAL ID 3 | L |
| TERMINAL 3 SIZE | Spade |
| TERMINAL ID 4 | R |
| TERMINAL 4 SIZE | Spade |
| POLARITY | Negative |
| NUMBER OF GROOVES | 1 |
| PULLEY TYPE | Solid |
| PULLEY OUTER DIAMETER | 2.717″ |
| PULLEY OUTER DIAMETER | 69mm |
| WARRANTY | 1 Year |
