NEW Alternator for Farm, Industrial & Marine Applications; AHI0081, 400-44040, 3282883M91, 3282-883-M91, LR135-126, LR135-58, LR135-58B; LESTER 12111, 12129

NEW Alternator for Farm, Industrial & Marine Applications; AHI0081, 400-44040, 3282883M91, 3282-883-M91, LR135-126, LR135-58, LR135-58B; LESTER 12111, 12129

Name: NEW Alternator for Farm, Industrial &amp; Marine Applications; AHI0081, 400-44040, 3282883M91, 3282-883-M91, LR135-126, LR135-58, LR135-58B; LESTER 12111, 12129
SKU: 11061
Availability: InStock

$169.99 $192.09

Categories: Alternator, Engine - Industrial, Engine - Marine, Tractor

Specifications

Unit Type	Alternator
VOLT	12
AMPS	35
REGULATOR CLOCK	2:00
FAN LOCATION	External
REGULATOR LOCATION	Internal
TERMINAL ID 2	B+
TERMINAL 2 SIZE	M5x0.8
MOUNT HOLE ID 1	M8x1.25
MOUNT HOLE 1 TYPE	Threaded
MOUNT HOLE 2 TYPE	Unthreaded
MOUNT HOLE ID 3	8.500mm
MOUNT HOLE 3 TYPE	Unthreaded
POLARITY	Negative
NUMBER OF GROOVES	1
PULLEY TYPE	Solid
Addn Info	Gehl, Isuzu, Massey Ferguson Used on Allis Chalmers, Deutz-Allis, White, and Yanmar Applications.

WRITE YOUR OWN REVIEW

We appreciate your feedback about our parts, services experience or anything which may help us to serve you better.

[testimonial_view id=”1″]

Applications

MAKE	MODEL	ENGINE	YEAR
Allis Chalmers	5020	2-77 Diesel , Diese	1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985
Allis Chalmers	5020	2-77 Toyosha Ds	1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985
Allis Chalmers	5030	2-90 Diesel , Diese	1979, 1980, 1981, 1982, 1983, 1984, 1985
Allis Chalmers	5030	2-90 Toyosha Ds	1979, 1980, 1981, 1982, 1983, 1984, 1985
Allis Chalmers	6140	3-142 Diesel , Diese	1982, 1983, 1984, 1985
Allis Chalmers	6140	3-142 Toyosha Ds	1982, 1983, 1984, 1985
Deutz-Allis	5220	Diesel , Diese	1986, 1987, 1988, 1989, 1990, 1991, 1992
Deutz-Allis	5220	Toyosha Diese	1986, 1987, 1988, 1989, 1990, 1991, 1992
Deutz-Allis	5230	Diesel , Diese	1986, 1987, 1988, 1989, 1990, 1991, 1992
Deutz-Allis	5230	Toyosha Diese	1986, 1987, 1988, 1989, 1990, 1991, 1992
Isuzu	Misc. Industrial Equipment	3AE1 Engin
Isuzu	Misc. Industrial Equipment	4JB1 Engin
Isuzu	Misc. Industrial Equipment	C240 Engin
Massey Ferguson	MF-1030	3-87 Diesel , Diese	1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991
Massey Ferguson	MF-1030	Toyosha 3-87 Diese	1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991
Massey Ferguson	MF-1035	3-92 Diesel , Diese	1986, 1987, 1988, 1989, 1990, 1991
Massey Ferguson	MF-1035	Toyosha 3-92 Diese	1986, 1987, 1988, 1989, 1990, 1991
Massey Ferguson	MF-1040	3-122 Diesel , Diese	1984, 1985, 1986
Massey Ferguson	MF-1040	Toyosha 3-122 Diese	1984, 1985, 1986
Massey Ferguson	MF-1045	3-122 Diesel , Diese	1986, 1987, 1988, 1989, 1990
Massey Ferguson	MF-1045	Toyosha 3-122 Diese	1986, 1987, 1988, 1989, 1990
Massey Ferguson	MF-205	2-77 Diesel , Diese	1979, 1980, 1981, 1982, 1983, 1984
Massey Ferguson	MF-205	Toyosha 2-77 Diese	1979, 1980, 1981, 1982, 1983, 1984
Massey Ferguson	MF-210	2-77 Diesel , Diese	1979, 1980, 1981, 1982, 1983, 1984
Massey Ferguson	MF-210	Toyosha 2-77 Diese	1979, 1980, 1981, 1982, 1983, 1984
Massey Ferguson	MF-210-4	2-77 Diesel , Diese	1979, 1980, 1981, 1982, 1983, 1984
Massey Ferguson	MF-210-4	Toyosha 2-77 Diese	1979, 1980, 1981, 1982, 1983, 1984
Massey Ferguson	MF-220	2-90 Diesel , Diese	1979, 1980, 1981, 1982, 1983, 1984
Massey Ferguson	MF-220	Toyosha 2-90 Diese	1979, 1980, 1981, 1982, 1983, 1984
Massey Ferguson	MF-220-4	2-90 Diesel , Diese	1979, 1980, 1981, 1982, 1983, 1984
Massey Ferguson	MF-220-4	Toyosha 2-90 Diese	1979, 1980, 1981, 1982, 1983, 1984
Nissan	620	1952cc, 2.0L L4 L20B	1978, 1979
Nissan	720	1952cc, 2.0L L4 L20B	1980
TCM Equipment	FD10Z	4FE1 Engin
TCM Equipment	FD14Z	4FE1 Engin
TCM Equipment	FD15Z	4FE1 Engin
TCM Equipment	FD18Z	4FE1 Engin
TCM Equipment	FD20Z	4FE1 Engin
TCM Equipment	FD23Z	4FE1 Engin
TCM Equipment	FD25Z	4FE1 Engin
TCM Equipment	FD9Z	4FE1 Engin
White	21 4WD Field Boss	Iseki 3-71 Ds	1987, 1988, 1989
White	21 Field Boss	Iseki 3-71 Ds	1987, 1988, 1989
White	37 4WD Field Boss	Isuzu 4-111 Ds	1987, 1988, 1989
White	37 Field Boss	Isuzu 4-111 Ds	1987, 1988, 1989
White	43 4WD Field Boss	Isuzu 4-145 Ds	1987, 1988, 1989
White	43 Field Boss	Isuzu 4-145 Ds	1987, 1988, 1989
Yanmar	1GM	1cyl 19.41ci 0.318	1980, 1981, 1982, 1983, 1984
Yanmar	1GM	Al
Yanmar	1GM	Al	1982, 1983, 1984
Yanmar	1GM		1985
Yanmar	1GM10	1cyl 19.41ci 0.318
Yanmar	1GM10	1cyl 19.41ci 0.318
Yanmar	1GM10	318cc, 318cc 1-Cyl Diesel , Diesel	1982
Yanmar	1GM10C	1cyl 19.41ci 0.318	1982, 1983, 1984
Yanmar	1GM10L	1cyl 19.41ci 0.318
Yanmar	1GM10L	1cyl 19.41ci 0.318
Yanmar	1GM10L	318cc, 318cc 1-Cyl Diesel , Diesel	1982
Yanmar	1GM10VE	1cyl 19.41ci 0.318
Yanmar	1GM10VE	318cc, 318cc 1-Cyl Diesel , Diesel	1985
Yanmar	1GML	1cyl 19.41ci 0.318
Yanmar	1GML	1cyl 19.41ci 0.318
Yanmar	1GML	318cc, 318cc 1-Cyl Diesel , Diesel	1982
Yanmar	1GMY	1cyl 19.41ci 0.318
Yanmar	1GMY	1cyl 19.41ci 0.318
Yanmar	1GMY	318cc, 318cc 1-Cyl Diesel , Diesel	1982
Yanmar	2GM	2cyl Diese	1980, 1981, 1982, 1983, 1984
Yanmar	2GM	Al
Yanmar	2GM	Al	1982, 1983, 1984
Yanmar	2GM		1985
Yanmar	2GM20	2cyl 38.81ci 0.636
Yanmar	2GMF	2cyl Diese	1980, 1981, 1982, 1983, 1984
Yanmar	2GMFL	2cyl Diese
Yanmar	2GMFY(E)-E	2cyl Diese
Yanmar	2GML	2cyl Diese
Yanmar	2GMYE-EC	2cyl Diese
Yanmar	2GMZ	2cyl 0.586L Diese
Yanmar	2QM15	2cyl 0.662L Diese	1977, 1978, 1979, 1980
Yanmar	2TD	2cyl Diese
Yanmar	2TM	2cyl Diese
Yanmar	3GM	3cyl Diese	1980, 1981, 1982, 1983, 1984
Yanmar	3GM	Al
Yanmar	3GM	Al	1982, 1983, 1984
Yanmar	3GM		1985
Yanmar	3GMD	3cyl Diese
Yanmar	3GMF	3cyl Diese
Yanmar	3GMFY-E	3cyl Diese
Yanmar	3GMLE	3cyl Diese
Yanmar	3GMLE	3cyl Diese
Yanmar	3GMLE	3-Cyl Diesel , Diese	1982
Yanmar	3HM	3cyl Diese	1980, 1981, 1982, 1983, 1984
Yanmar	3HM	Al
Yanmar	3HM	Al	1982, 1983, 1984
Yanmar	3HM		1985
Yanmar	3HMF	3cyl Diese	1980, 1981, 1982, 1983, 1984
Yanmar	3JH2	3cyl Diese	1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999
Yanmar	3JH3	3cyl Diese	1999, 2000, 2001, 2002, 2003
Yanmar	3JH3Z	3cyl Diese
Yanmar	3TD	Al
Yanmar	3TM	Al
Yanmar	4GM	4cyl Diese
Yanmar	4GM	Al
Yanmar	4GM		1985
Yanmar	4JH	4cyl Diese
Yanmar	4JH2L-HTNE	4cyl Diese
Yanmar	4JH2L-TNE	4cyl Diese
Yanmar	4JH3	4cyl Diese	1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003
Yanmar	4JH3ZA	4cyl Diese	1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003
Yanmar	4JH-HT	4cyl Diese
Yanmar	4JH-HT-Z	4cyl Diese
Yanmar	4JH-T	4cyl Diese
Yanmar	4JH-TZ	4cyl Diese
Yanmar	4JHZ	4cyl Diese
Yanmar	4TD	4cyl Diese
Yanmar	4TM	4cyl Diese
Yanmar	KM2A
Yanmar	KM2A
Yanmar	KM2A
Yanmar	KM2P
Yanmar	KM2P
Yanmar	KM2P
Yanmar	KM3V
Yanmar	KM3V
Yanmar	KM3V
Yanmar	Y-5M
Yanmar	Y-5M
Yanmar	Y-5M

Manufacturer Name	Manufacturer Part #
ARROWHEAD	AHI0081
ATLANTIC QUALITY PARTS	1200-0514
EMP	4-6927
HITACHI	LR135-126, LR135-58, LR135-58B
ISUZU	5001810100
J&N	400-44040
LUCAS ELECTRIC	LRA01191
MASSEY FERGUSON	3282883M91, 3282-883-M91
WHITE	33-0134376, 33-0135895
