NEW Alternator for FIAT 500 1.4L Application; 400-52470, 68070539AA, RL070593AA, 101210-1650, MS101210-1650; LESTER 11599
$189.99
Specifications
| UNIT TYPE | ALTERNATOR |
| VOLT | 12 |
| AMPS | 105 |
| REGULATOR CLOCK | 2:00 |
| ROTATION DIRECTION | Clockwise |
| MOUNT HOLE ID 1 | 8.300mm |
| MOUNT HOLE 1 TYPE | Unthreaded |
| MOUNT HOLE 2 TYPE | Unthreaded |
| MOUNT HOLE ID 3 | 8.600mm |
| MOUNT HOLE 3 TYPE | Unthreaded |
| MOUNTING EAR THICKNESS | 1″ |
| MOUNTING EAR THICKNESS | 25.400mm |
| MOUNTING EAR 2 THICKNESS | 0.945″ |
| MOUNTING EAR 2 THICKNESS | 24mm |
| MOUNTING EAR 3 THICKNESS | 0.945″ |
| MOUNTING EAR 3 THICKNESS | 24mm |
| FAN LOCATION | Internal |
| REGULATOR LOCATION | Internal |
| TERMINAL ID 2 | B+ |
| TERMINAL 2 SIZE | M8x1.25 |
| TERMINAL ID 3 | D+ |
| TERMINAL 3 SIZE | M5x0.8 |
| POLARITY | Negative |
| NUMBER OF GROOVES | 5 |
| GROOVE OD | 2.165″ |
| GROOVE OD | 55mm |
| PULLEY TYPE | Solid |
| PULLEY OUTER DIAMETER | 2.362″ |
| PULLEY OUTER DIAMETER | 60mm |
WRITE YOUR OWN REVIEW
We appreciate your feedback about our parts, services experience or anything which may help us to serve you better.
[testimonial_view id=”1″]
Part Number & Interchanges
| Manufacturer Name | Manufacturer Part # |
| ARROWHEAD | 400-52470 |
| CHRYSLER MOTORS | 68070539AA, RL070593AA |
| DENSO | 101210-1650, MS101210-1650 |
| LESTER | 11599 |
Part fit
| Year | Make | Model | Engine |
|---|---|---|---|
| Year | Make | Model | Engine |
| 2012 - 2013 | FIAT | 500 | 1.4L |
