NEW Alternator for FORD / NEW HOLLAND Tractors; 400-41014, F2NN-10B376-AA, 82001259, 82002329, 82003307, 82010243, [MARELLI063321347010, 63321347, 63340015, MAN787]; LESTER 12095
$219.99
Search: MARELLI Alt
Specifications
| UNIT TYPE | Alternator |
| VOLT | 12 |
| AMPS | 100 |
| REGULATOR CLOCK | 5:00 |
| ROTATION DIRECTION | Clockwise |
| MOUNT HOLE ID 1 | M8x1.25 |
| MOUNT HOLE 1 TYPE | Threaded |
| MOUNT HOLE 2 TYPE | Unthreaded |
| MOUNT HOLE ID 3 | 8.500mm |
| MOUNT HOLE 3 TYPE | Unthreaded |
| MOUNTING EAR THICKNESS | 0.535″ |
| MOUNTING EAR THICKNESS | 13.600mm |
| MOUNTING EAR 2 THICKNESS | 0.535″ |
| MOUNTING EAR 2 THICKNESS | 13.600mm |
| MOUNTING EAR 3 THICKNESS | 0.787″ |
| MOUNTING EAR 3 THICKNESS | 20mm |
| FAN LOCATION | Internal |
| REGULATOR LOCATION | Internal |
| TERMINAL ID 2 | B+ |
| TERMINAL 2 SIZE | M6x1.00 |
| TERMINAL ID 3 | D+ |
| TERMINAL 3 SIZE | M5x0.8 |
| TERMINAL ID 4 | W |
| TERMINAL 4 SIZE | M5x0.8 |
| POLARITY | Negative |
| NUMBER OF GROOVES | 8 |
| PULLEY TYPE | Solid |
| PULLEY OUTER DIAMETER | 2.598″ |
| PULLEY OUTER DIAMETER | 66mm |
WRITE YOUR OWN REVIEW
We appreciate your feedback about our parts, services experience or anything which may help us to serve you better.
[testimonial_view id=”1″]
Part Number & Interchanges
| Manufacturer Name | Manufacturer Part # |
| ARROWHEAD | IA1019, MG246 |
| ATLANTIC QUALITY PARTS | 1100-0509 |
| FORD | F2NN-10B376-AA |
| FORD/NEW HOLLAND | 82001259, 82002329, 82003307, 82010243 |
| J&N ELECTRICAL PRODUCTS | 400-30031, 400-41014 |
| LESTER | 12094 |
| LETRIKA/ISKRA | IA 1019 |
| LUCAS ELECTRIC | LRB286 |
| MAHLE | MG246 |
| MARELLI | 063321347010, 63321347, 63340015, MAN787 |
Applications
Part fit
| MAKE | MODEL | ENGINE | YEAR |
| Ford | 5640 | 268ci – 4cyl Ds | 1992, 1993, 1994, 1995, 1996, 1997, 1998 |
| Ford | 6640 | 304ci – 4cyl Ds | 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998 |
| Ford | 7740SLE | 4-304 Ds | 1994, 1995, 1996, 1997 |
| Ford | 7840SLE | 6-401 Ds | 1994, 1995, 1996, 1997 |
| Ford | 8160 | 6-456 Ds | 1996, 1997, 1998 |
| Ford | 8240SLE | 6-456 Ds | 1994, 1995, 1996, 1997 |
| Ford | 8260 | 6-456 Ds | 1996, 1997, 1998 |
| Ford | 8340SLE | 6-456 Ds | 1994, 1995, 1996, 1997 |
| Ford | 8360 | 6-456 Ds | 1996, 1997, 1998 |
| Ford | 8560 | 6-456 Ds | 1996, 1997, 1998 |
| New Holland | 5640 | 4-268 Ford Ds | 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998 |
| New Holland | 6530 | 4-268 Ford Ds | 1992, 1993, 1994, 1995, 1996, 1997 |
| New Holland | 6640 | 4-304 Ford Ds | 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998 |
| New Holland | 7740 | 4-304 Ford Ds | 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998 |
| New Holland | 7840 | 6-401 Ford Ds | 1991, 1992, 1993, 1994, 1995, 1996 |
| New Holland | 8010 | 6-456 Ds | 1996, 1997, 1998, 1999, 2000 |
| New Holland | 8010 | 6-456 Ford Ds | 1996, 1997, 1998, 1999, 2000 |
| New Holland | 8010HC | 6-456 Ds | 1997, 1998, 1999 |
| New Holland | 8010HC | 6-456 Ford Ds | 1997, 1998, 1999 |
| New Holland | 8160 | 6-456 Ds | 1996, 1997, 1998, 1999 |
| New Holland | 8160 | 6-456 Ford Ds | 1996, 1997, 1998, 1999 |
| New Holland | 8240 | 6-456 Ford Ds | 1992, 1993, 1994, 1995, 1996, 1997 |
| New Holland | 8340 | 6-456 Ford Ds | 1992, 1993, 1994, 1995, 1996, 1997 |
| New Holland | 8360 | 6-456 Ds | 1996, 1997, 1998, 1999 |
| New Holland | 8360 | 6-456 Ford Ds | 1996, 1997, 1998, 1999 |
| New Holland | 8560 | 6-456 Ds | 1996, 1997, 1998, 1999 |
| New Holland | 8560 | 6-456 Ford Ds | 1996, 1997, 1998, 1999 |
| New Holland | TS100 | 5.0L 4cyl Turb | 1998, 1999, 2000, 2001, 2002, 2003 |
| New Holland | TS110 | 5.0L 4cyl Turb | 1998, 1999, 2000, 2001, 2002, 2003 |
| New Holland | TS115 | 7.5L 6cyl Ds | 1998, 1999, 2000, 2001, 2002, 2003 |
| New Holland | TS90 | 5.0L 4cyl | 1998, 1999, 2000, 2001, 2002, 2003 |
| New Holland | TV140 Bi-Directional | NH 6-456 Turbo Ds | 1998, 1999, 2000, 2001, 2002 |
