NEW Alternator for MAZDA MPV 2002-2006 Applications; 400-48086, AJ15-18-300, AJ51-18-300, AJ51-18-300A, AJ51-18-300R00, A003TJ0191ZC, A3TJ0191, A3TJ0191A; LESTER 11006
December 1, 2019NEW Alternator for KIA & MAZDA Applications; 400-48134, MZ599-18-300A, A2TB0091; LESTER 13718
December 1, 2019NEW Alternator for MAZDA 6 2003-2005 Application; 400-48082, L813-18-300, L816-18-300, A3TG0091, A3TG0091A; LESTER 11005
$259.99
Specifications
UNIT TYPE | Alternator |
CRITICAL NOTE | To Avoid Regulator Damage Consult Your Test Equipment Manufacturer for the Proper Procedure for Testing Alternators With P-D Type Regulators |
VOLT | 12 |
AMPS | 90 |
REGULATOR CLOCK | 3:00 |
ROTATION DIRECTION | Clockwise |
MOUNT HOLE ID 1 | 10.300mm |
MOUNT HOLE 1 TYPE | Unthreaded |
MOUNT HOLE 2 TYPE | Slotted |
MOUNT HOLE ID 3 | 12.200mm |
MOUNT HOLE 3 TYPE | Unthreaded |
MOUNTING EAR THICKNESS | 2.492″ |
MOUNTING EAR THICKNESS | 63.300mm |
MOUNTING EAR 2 THICKNESS | 2.362″ |
MOUNTING EAR 2 THICKNESS | 60mm |
MOUNTING EAR 3 THICKNESS | 2.362″ |
MOUNTING EAR 3 THICKNESS | 60mm |
FAN LOCATION | Internal |
REGULATOR LOCATION | Internal |
TERMINAL ID 2 | B+ |
TERMINAL 2 SIZE | M8x1.25 |
TERMINAL ID 3 | P |
TERMINAL 3 SIZE | Spade |
TERMINAL ID 4 | D |
TERMINAL 4 SIZE | Spade |
POLARITY | Negative |
NUMBER OF GROOVES | 6 |
PULLEY TYPE | Solid |
PULLEY OUTER DIAMETER | 2.319″ |
PULLEY OUTER DIAMETER | 58.900mm |
WARRANTY | 1 Year |
Plastic Shield Attached to SRE Housing |
WRITE YOUR OWN REVIEW
We appreciate your feedback about our parts, services experience or anything which may help us to serve you better.
[testimonial_view id=”1″]
Part Number & Interchanges
Manufacturer Name | Manufacturer Part # |
ARROWHEAD | A3TG0091A, AMT0138 |
BOSCH | 0986032391, AL4237X |
DENSO | 210-4243 |
J&N ELECTRICAL PRODUCTS | 400-48082 |
LESTER | 11005 |
LUCAS ELECTRIC | LRA01166 |
MAZDA | L813-18-300, L816-18-300 |
MITSUBISHI | A3TG0091, A3TG0091A |
Part fit
Year | Make | Model | Engine |
---|---|---|---|
Year | Make | Model | Engine |
2003 - 2005 | MAZDA | 6 | 2.3L |
