June 25, 2020New PM Alternator for KUBOTA Compact Tractors; 400-58002, 15531-64013, 15531-64016, 15531-64017, 6A830-59250, 6C040-59250, 6C040-59252, EG673-64010, KEARA15531; LESTER 10932, 10935, 10938
$129.99
Specifications
UNIT TYPE | Alternator |
CRITICAL NOTE | 14 Amp Version |
VOLT | 12 |
AMPS | 14 |
MOUNT HOLE ID 1 | M8x1.25 |
MOUNT HOLE 1 TYPE | Threaded |
MOUNT HOLE 2 TYPE | Unthreaded |
MOUNTING EAR THICKNESS | 0.610″ |
MOUNTING EAR THICKNESS | 15.500mm |
MOUNTING EAR 2 THICKNESS | 0.610″ |
MOUNTING EAR 2 THICKNESS | 15.500mm |
REGULATOR LOCATION | External |
NUMBER OF GROOVES | 1 |
PULLEY TYPE | Solid |
PULLEY OUTER DIAMETER | 2.598″ |
PULLEY OUTER DIAMETER | 66mm |
WARRANTY | 1 Year |
ADD’L INFO | Permanent Magnet, Harness Exits Rear at 7:00 |
Part Number & Interchanges
Manufacturer Name | Manufacturer Part # |
ARROWHEAD | AMT0119, APM0003 |
CUMMINS | 0185-5431 |
J&N | 400-58015 |
KIOTI | E5700-64013, E5700-64014 |
KUBOTA | 15531-64013, 15531-64016, 15531-64017, 6A830-59250, 6C040-59250, 6C040-59252, EG673-64010, KEARA15531 |
LESTER | 10932, 10935, 10938 |
ONAN | 0185-5431 |
Applications
Make | Model | Engine | Year |
Kubota | B1550D | 17HP Diesel | 1988 – 1996 |
Kubota | B1550E | 17HP Diesel | 1988 – 1996 |
Kubota | B1700DT | 17HP Diesel | 1995 – 1998 |
Kubota | B1700E | 17HP Diesel | 1995 – 1998 |
Kubota | B1700HSD | 17HP Diesel | 1995 – 1998 |
Kubota | B1700HSDB | 17HP Diesel | 1995 – 1998 |
Kubota | B20 | 20HP Diesel | 1990 – 1998 |
Kubota | B20TL | 20HP Diesel | 1990 – 1998 |
Kubota | B2100DT | 21HP Diesel | 1995 – 1998 |
Kubota | B2100HSD | 21HP Diesel | 1995 – 1998 |
Kubota | B2100HSDB | 21HP Diesel | 1995 – 1998 |
Kubota | B2400HST-DB | 24HP Diesel | 1995 – 1998 |
Kubota | B2400HST-E | 24HP Diesel | 1995 – 1998 |
Kubota | B2410HSDB | 24HP Diesel | 1995 – 1998 |
Kubota | B2410HSE | 24HP Diesel | 1995 – 1998 |
Kubota | B2630HSD | 26HP Diesel | 2009 |
Kubota | B2710HSD | 27HP Diesel | 1996 |
Kubota | B2910HSD | 30HP Diesel | 1996 |
Kubota | B3030HSD | Diesel | 2009 |
Kubota | B3030HSDC | Diesel | 2009 |
Kubota | B5200DT | 13HP Diesel | 1983 – 1996 |
Kubota | B5200E | 13HP Diesel | 1983 – 1995 |
Kubota | B6200DT | 15HP Diesel | 1983 – 1994 |
Kubota | B6200E | 15HP Diesel | 1983 – 1994 |
Kubota | B6200HSD | 15HP Diesel | 1983 – 1994 |
Kubota | B6200HSDT | 15HP Diesel | 1983 – 1994 |
Kubota | B6200HSE | 15HP Diesel | 1983 – 1994 |
Kubota | B6200HST | 15HP Diesel | 1983 – 1994 |
Kubota | B6200T | 15HP Diesel | 1983 – 1994 |
Kubota | B7300HSD | 16HP Diesel | 1997 – 1998 |
Kubota | B7400HSD | 16HP Diesel | 1997 – 1998 |
Kubota | B7410DT-F | 18HP Diesel | 2005 |
Kubota | B7410DT-R | 18HP Diesel | 2005 |
Kubota | B7500DT | 21HP Diesel | 1996 |
Kubota | B7800HSD-F | 30HP Diesel | 2003 – 2009 |
Kubota | B7800HSD-R | 30HP Diesel | 2003 – 2009 |
Kubota | B8200DT | 19HP Diesel | 1981 – 1990 |
Kubota | B8200E | 19HP Diesel | 1981 – 1990 |
Kubota | B8200HSD | 19HP Diesel | 1983 – 1990 |
Kubota | B8200HSE | 19HP Diesel | 1983 – 1990 |
Kubota | B8200HST | 19HP Diesel | 1983 – 1990 |
Kubota | B9200DT | 22HP V12 Diesel | 1987 – 1990 |
Kubota | B9200E | 22HP V12 Diesel | 1987 – 1990 |
Kubota | B9200HSD | 22HP V12 Diesel | 1987 – 1990 |
Kubota | B9200HSE | 22HP V12 Diesel | 1987 – 1990 |
Kubota | BX1500D | Z602E | 2003 |
Kubota | BX1800D | 18HP Diesel | 2001 – 2003 |
Kubota | BX1830D | 18HP Diesel | 2004 – 2006 |
Kubota | BX22 | 22HP Diesel | 2002 – 2003 |
Kubota | BX2200D | 22HP Diesel | 2001 – 2003 |
Kubota | BX2230D | 22HP Diesel | 2004 – 2006 |
Kubota | BX23LB | 22HP Diesel | 2004 – 2005 |
Kubota | F2000 | 20HP Diesel | 1986 – 1994 |
Kubota | F2100E | 21HP Diesel | 1989 – 1995 |
Kubota | G1800 | 16HP Diesel | 1989 – 1995 |
Kubota | G1800S | 16HP Diesel | 1989 – 1995 |
Kubota | G1900 | 18HP Diesel | 1989 – 1995 |
Kubota | G2000 | 21HP | 1989 – 1995 |
Kubota | G3200 | 10HP Diesel | 1983 – 1990 |
Kubota | G4200H | 12HP Diesel | 1984 – 1990 |
Kubota | G5200H | 14HP Diesel | 1984 – 1990 |
Kubota | G6200H | 16HP Diesel | 1986 – 1990 |
Kubota | GF1800-R | 18HP Diesel | 2005 |
Kubota | GF1800E-R | 18HP Diesel | 2005 |
Kubota | K008 | 10HP Diesel | 2000 |
Kubota | K008-3 | 10HP Diesel | 2000 |
Kubota | KH007 | 8HP Diesel | 1989 – 1993 |
Kubota | KH35 | 13HP Diesel | 1985 |
Kubota | KH41 | 17HP Diesel | 1988 |
Kubota | KH61 | 22HP Diesel | 1988 |
Kubota | RTV500 4×4 | 456cc | – |
Kubota | T1600H | 13HP | 1990 – 1995 |
Kubota | ZD18 | 18HP Diesel | 2005 |
Kubota | ZD21 | 21HP Diesel | 2005 |
Kubota | ZD25 | 28HP Diesel | 2005 |
Kubota | ZD28 | 28HP Diesel | 2005 |
