NEW Starter for MASSEY FERGUSON Applications; 410-30041, 26273, 26344, 26365, 26411, 27522, 27540, 27546, 27571, 27582B, 27584, LRS00301; LESTER 17653
June 4, 2020New MAHLE Starter for MASSEY FERGUSON Tractors with PERKINS Engines; MAH-MS149, 11.130.632, AZJ3206, IS0632, MS149; LESTER 17653
June 4, 2020NEW Starter for AGCO 5650, 5660 & MASSEY FERGUSON MF-243 Tractors – Farm ; 410-30011, 1691805M1, 1868-283-M2, 1868283M3, 1868-283-M3, 1868283M5, 3597371M2, 3763363M91, 3763363M94, 579487M91, 579-487-M91; LESTER 17653
$274.99
SEARCH OTHER VERSIONS: SLU0011, ISKRA 2.8kw DD, ISKRA 3.0kw DD, ISKRA 3.2kw PLGR, MAGNETON OSGR
Specifications
UNIT TYPE | Starter |
FAMILY | Lucas M127 |
ELECTRIC STARTER TYPE | Direct Drive (DD) |
VOLT | 12 |
POWER | 2.800 kw |
HP | 3.755 |
ROTATION DIRECTION | Clockwise |
NUMBER OF TEETH | 10 |
GEAR OD | 1.575″ |
GEAR OD | 40mm |
MOUNT HOLE ID 1 | 13mm |
MOUNT HOLE 1 TYPE | Unthreaded |
MOUNT HOLE 2 TYPE | Unthreaded |
MOUNT HOLE ID 3 | 13mm |
MOUNT HOLE 3 TYPE | Unthreaded |
WARRANTY | 1 Year |
Middle Mounting Hole Is Oblong |
Part Number & Interchanges
Manufacturer Name | Manufacturer Part # |
ARROWHEAD | IS0632, IS1046, IS1395, L26025124A, MS149, MS206, MS243, SLU0011 |
J&N ELECTRICAL PRODUCTS | 410-30011, 410-30041 |
LESTER | 17653 |
LETRIKA/ISKRA | IS 0632, IS 1046 |
LUCAS ELECTRIC | 26273, 26273A, 26273B, 26273C, 26273D, 26273E, 26273F, 26273H, 26273I, 26273J, 26273K, 26273L, 26273M, 26344, 26344A, 26344B, 26344C, 26344D, 26344E, 26344F, 26365, 26365A, 26365B, 26365C, 26365D, 26365E, 26365F, 26403, 26403A, 26403B, 26403C, 26403D, 26411, 26411A, 26411B, 27522, 27522A, 27522B, 27522C, 27522D, 27540, 27540A, 27540B, 27540C, 27540D, 27540E, 27540F, 27546, 27546A, 27546B, 27571, 27582, 27582B, 27584, 60925087, 60925088, LRS00301, LRS301, NSB530, S5026, S5032 |
LUCAS TVS | 26025124A |
MAHLE | IS0632, MS149, MS206, MS243 |
MASSEY FERGUSON | 1691805M1, 1868-283-M2, 1868283M3, 1868-283-M3, 1868283M5, 3597371M2, 3763363M91, 3763363M94, 579487M91, 579-487-M91 |
PERKINS | 2873B061 |
Part fit
Year | Make | Model | Engine |
---|---|---|---|
Year | Make | Model | Engine |
1994 - 2000 | AGCO | 5650 | 3-183 Diesel |
1994 - 2000 | AGCO | 5660 | 3-183 Diesel |
1999 - 2000 | MASSEY FERGUSON | MF-243 | Perkins 3-165 Diesel |
