NEW Starter for BENELLI Velvet 125, Velvet 150 & YAMAHA Vino YJ125 Scooters; 410-54185, R19010111A0, 4TE-H1800-10-00; LESTER 18841
June 26, 2020
NEW Starter for APRILIA BENELLI & YAMAHA Scooters; 410-54192, AP8122628, AP8552123, R19040191A0, 1CO-H1800-00-00, 1SD-H1800-00-00, 4HC81890-00-00; LESTER 18843
June 26, 2020
NEW Starter for YAMAHA YP400 Majesty Scooters; 410-54192, 1CO-H1800-00-00, 1SD-H1800-00-00, 4HC81890-00-00; LESTER 18843
$209.99
SEARCH: 485955 (EARLIER VERSION)
Specifications
| UNIT TYPE | Starter |
| ELECTRIC STARTER TYPE | Permanent Magnet Direct Drive (PMDD) |
| VOLT | 12 |
| ROTATION DIRECTION | Clockwise |
| NUMBER OF TEETH | 9 |
| GEAR OD | 0.457″ |
| GEAR OD | 11.600mm |
| MOUNT HOLE ID 1 | 6.500mm |
| MOUNT HOLE 1 TYPE | Unthreaded |
| MOUNT HOLE 2 TYPE | Unthreaded |
| WARRANTY | 1 Year |
Part Number & Interchanges
| Manufacturer Name | Manufacturer Part # |
| APRILIA | AP8122628, AP8552123 |
| ARROWHEAD | SMU0341 |
| BENELLI | R19040191A0 |
| HI LEVEL | STY0341 |
| J&N ELECTRICAL PRODUCTS | 410-54192 |
| LESTER | 18843 |
| MALAGUTI | 74800500, 94800100 |
| MITSUBA | SM13-454 |
| SOCIETA GENERALE RICAMBI | 17.8145, 17.81457 |
| YAMAHA | 1CO-H1800-00-00, 1SD-H1800-00-00, 4HC81890-00-00 |
Part fit
| Year | Make | Model | Engine |
|---|---|---|---|
| Year | Make | Model | Engine |
| 2013 - 2014 | YAMAHA | Majesty YP400 | 395cc |
