New PRESTOLITE Pump Motor for Monarch / Bucher Applications; PLMMY6304A, 08196, 50020500800316, MMY6304, MMY6304A
June 1, 2020
NEW Winch Motor for SUPERWINCH HUSKY SERIES & WARN WINCH Applications; 430-20066, 38894, 9130450047, 458058, M-1900, 226626, 9130450047; LESTER 10746HD
June 2, 2020
NEW Winch Motor for SUPERWINCH HUSKEY & WARN WINCH Applications; 430-20018, F000MM0626, F006MM0600, F006MM0601, F006MM0602, MRVB7; LESTER 10746, 10747
$184.99
INFO: TWO WAY ROTATION; wo/OVERLOAD DEVICE
SEARCH: DOUBLE BALL BEARING | w/DE FRAME ATTACHED | 4.8HP VERSION
Specifications
| UNIT TYPE | Winch Motor |
| CURRENT TYPE | DC |
| VOLT | 12 |
| POWER | 2 kw |
| HP | 2.682 |
| ROTATION DIRECTION | Reversible |
| OD | 114.300 mm |
| OD | 4.500″ |
| SHAFT OD | 0.654″ |
| SHAFT OD | 16.600mm |
| LENGTH | 232.500 mm |
| LENGTH | 9.154″ |
| TERMINAL 2 SIZE | M8-1.25 |
| TERMINAL 3 SIZE | M8-1.25 |
| TERMINAL 4 SIZE | M8-1.25 |
| SHAFT | 20 Straight Splines |
| WARRANTY | 1 Year |
| ADD’L INFO | 165.1mm (6.5″) Long Field Case
SUPERWINCH HUSKY SERIES, WARN WINCH |
Part Number & Interchanges
| Manufacturer Name | Manufacturer Part # |
| ARROWHEAD | LRW0002 |
| J & N | 430-20093 |
| LESTER | 10746 |
| BARSANCO | 540-025 |
| EMS | 10746N |
| MINNPAR | 67-2164 |
| NATL LIFTGATE PARTS | AMT0406 |
| NATL LIFTGATE PARTS | AMT0470 |
| PRESTOLITE | MRVB4 |
| REFERENCE NUMBER | 15747 |
| REFERENCE NUMBER | 11212449 |
| REFERENCE NUMBER | 226626 |
| REFERENCE NUMBER | 18184 |
| REFERENCE NUMBER | D-2000 |
| REFERENCE NUMBER | 458058 |
| REFERENCE NUMBER | AMJ4635 |
| REFERENCE NUMBER | 15877 |
| REFERENCE NUMBER | 26629 |
| REFERENCE NUMBER | M1900 |
| REFERENCE NUMBER | 17102 |
| SUPER WINCH | 7682 |
| SUPER WINCH | 7536 |
| WAI | 82-6867 |
| WAI | 10746N-DB |
| WAI (OLD) | 82-6867 |
| WAPSA | 9130450047 |
| WESTERN MOTORS | W-8923 |
