$199.99
Specifications
UNIT TYPE | Alternator |
FAMILY | Denso SC (Hairpin) |
VOLT | 12 |
AMPS | 130 |
REGULATOR CLOCK | 11:00 |
ROTATION DIRECTION | Clockwise |
MOUNT HOLE ID 1 | 9mm |
MOUNT HOLE 1 TYPE | Unthreaded |
MOUNT HOLE 2 TYPE | Unthreaded |
MOUNTING EAR THICKNESS | 0.748″ |
MOUNTING EAR THICKNESS | 19mm |
MOUNTING EAR 2 THICKNESS | 1.811″ |
MOUNTING EAR 2 THICKNESS | 46mm |
FAN LOCATION | Internal |
REGULATOR LOCATION | Internal |
TERMINAL ID 2 | B+ |
TERMINAL 2 SIZE | M8x1.25 |
TERMINAL ID 3 | Ign |
TERMINAL 3 SIZE | Spade |
TERMINAL ID 4 | C |
TERMINAL 4 SIZE | Spade |
TERMINAL ID 5 | L |
TERMINAL 5 SIZE | Spade |
TERMINAL ID 6 | FR |
TERMINAL 6 SIZE | Spade |
POLARITY | Negative |
NUMBER OF GROOVES | 6 |
PULLEY TYPE | Solid |
PULLEY OUTER DIAMETER | 2.807″ |
PULLEY OUTER DIAMETER | 71.300mm |
WARRANTY | 1 Year |
WRITE YOUR OWN REVIEW
We appreciate your feedback about our parts, services experience or anything which may help us to serve you better.
[testimonial_view id=”1″]
Part Number & Interchanges
Manufacturer Name | Manufacturer Part # |
ACURA | 31100-RDJ-A01, 31100-RGL-A01, CSC10, CSD29 |
ARROWHEAD | AND0308, AND0339, AND0340, AND0408, VND0339 |
BOSCH | AL1297X, AL1300X |
DENSO | 104210-3100, 104210-4290, 104210-4300, 104210-4301, 104210-4690, 210-0580 |
HONDA | 31100-RGL-A01, 31100-RGM-A01, 31100-RJA-A01, 31100RJA-A01, 31100-RJA-A02, 31100RJA-A02, 31100-RYP-A01, CSD29, CSD30, CSD69 |
J&N | 400-52163, 400-52252, 400-52252R |
LESTER | 11099, 11150, 11151 |
LUCAS ELECTRIC | LRA01621, LRA04171 |
Part fit
Year | Make | Model | Engine |
---|---|---|---|
Year | Make | Model | Engine |
2005 - 2008 | ACURA | RL | 3.5L |
2006 | ACURA | MDX | 3.5L |
2006 - 2008 | ACURA | TL | 3.2L |
2007 | HONDA | ODYSSEY | 3.5L |
2007 - 2008 | ACURA | MDX | 3.7L |
2007 - 2008 | ACURA | TL | 3.5L |
2007 - 2008 | HONDA | PILOT | 3.5L |
2007 - 2008 | HONDA | RIDGELINE | 3.5L |
