NEW Alternator for CHRYSLER & DODGE Applications; AND0301, 4608826AA, 210-0564, 421000-0180; LESTER 11048
$237.99
Specifications
| UNIT TYPE | Alternator |
| FAMILY | Denso SC (Hairpin) |
| VOLT | 12 |
| AMPS | 150 |
| REGULATOR CLOCK | 2:30 |
| ROTATION DIRECTION | Clockwise |
| MOUNT HOLE ID 1 | 11.200mm |
| MOUNT HOLE 1 TYPE | Unthreaded |
| MOUNT HOLE 2 TYPE | Unthreaded |
| MOUNT HOLE ID 3 | 10.500mm |
| MOUNT HOLE 3 TYPE | Unthreaded |
| MOUNTING EAR THICKNESS | 0.512″ |
| MOUNTING EAR THICKNESS | 13mm |
| MOUNTING EAR 2 THICKNESS | 0.512″ |
| MOUNTING EAR 2 THICKNESS | 13mm |
| MOUNTING EAR 3 THICKNESS | 0.787″ |
| MOUNTING EAR 3 THICKNESS | 20mm |
| FAN LOCATION | Internal |
| REGULATOR LOCATION | External |
| TERMINAL ID 2 | B+ |
| TERMINAL 2 SIZE | M8x1.25 |
| TERMINAL ID 3 | F1 |
| TERMINAL 3 SIZE | Spade |
| TERMINAL ID 4 | F2 |
| TERMINAL 4 SIZE | Spade |
| POLARITY | Negative |
| NUMBER OF GROOVES | 6 |
| PULLEY TYPE | Solid |
WRITE YOUR OWN REVIEW
We appreciate your feedback about our parts, services experience or anything which may help us to serve you better.
[testimonial_view id=”1″]
Part Number & Interchanges
| Manufacturer Name | Manufacturer Part # |
| ARROWHEAD | AND0301, VND0301 |
| BOSCH | AL6448X |
| CHRYSLER MOTORS | 4608826AA |
| DENSO | 210-0564, 421000-0180 |
| J&N ELECTRICAL PRODUCTS | 400-52147, 400-52580 |
| JANNCO | 400-52580R |
| LESTER | 11048 |
Part fit
| Year | Make | Model | Engine |
|---|---|---|---|
| Year | Make | Model | Engine |
| 2003 - 2004 | CHRYSLER | 300 SERIES | 3.5L(215) V6 |
| 2003 - 2004 | CHRYSLER | CONCORDE | 3.5L(215) V6 |
| 2003 - 2004 | DODGE | INTREPID | 3.5L(215) V6 |
