Specifications
| Unit Type |
Alternator |
| Part Type |
UNIT |
| VOLT |
12 |
| AMPS |
40 |
| REGULATOR CLOCK |
9:00 |
| FAN LOCATION |
Internal |
| REGULATOR LOCATION |
Internal |
| TERMINAL ID 2 |
B+ |
| TERMINAL 2 SIZE |
M6x1.00 |
| POLARITY |
Negative |
WRITE YOUR OWN REVIEW
We appreciate your feedback about our parts, services experience or anything which may help us to serve you better.
[testimonial_view id=”1″]
Part Number & Interchanges
| Manufacturer Name |
Manufacturer Part # |
| ARROWHEAD |
AND0212 |
| J&N |
400-52014 |
| KUBOTA |
16231-24011, 16231-6401, 16231-64011, 16231-64012, 16241-64010, 16241-64011, 16241-64012, 66436-64012, 66436-64013, KEARA16231, KEARA16241 |
| DENSO |
100211-1670, 100211-1671, 100211-4520, 100211-4521, 100211-4740, 100211-4741, 9760218-167, 9760218-452 |
| CARRIER TRANSICOLD |
96-111-02K |
| JANNCO |
400-52014R |
Applications
| YEAR |
MAKE |
TYPE |
MODEL |
ENGINE |
| 1994 – 2001 |
CASE |
Trenchers |
460 |
Kubota V1505-B Dsl |
| 1997 – 2000 |
CASE |
Trenchers |
6010 |
Kubota V2203 Dsl |
| 1997 – 1999 |
CASE |
Uni-Loaders |
1825B |
Kubota Engine |
| 1995 – 1999 |
CASE |
Uni-Loaders |
1838 |
Kubota Engine |
| All |
GRASSHOPPER |
Tractors – Lawn |
928D |
Kubota 28HP Dsl |
| All |
GRAVELY |
Tractors – Lawn |
PM460 |
Kubota 30HP Dsl |
| 92-On |
KUBOTA |
Excavators |
KX41 |
Kubota D1105BH 22HP Dsl |
| 95-On |
KUBOTA |
Excavators |
KX41-2 |
Kubota D1105BH 21.6HP Dsl |
| 00-On |
KUBOTA |
Excavators |
KX41-2S |
Kubota D1105BH 21.6HP Dsl |
| 00-On |
KUBOTA |
Excavators |
KX41-2SV |
Kubota D1105BH 21.6HP Dsl |
| 05-Bk |
KUBOTA |
Excavators |
KX41-3 |
Kubota D902EBH 17HP Dsl |
| 95-On |
KUBOTA |
Excavators |
KX61-2 |
Kubota D1105BH 27HP Dsl |
| 95-On |
KUBOTA |
Excavators |
KX61-2S |
Kubota D1105BH 27HP Dsl |
| 03-Bk |
KUBOTA |
Excavators |
KX71H |
Kubota V1505BH 32.2HP Dsl |
| 97-01 |
KUBOTA |
Excavators |
KX91-2 |
Kubota V1505BH 27.5HP Dsl |
| 00-On |
KUBOTA |
Excavators |
KX91-2S |
Kubota V1505EBH 27.5HP Dsl |
| 89-On |
KUBOTA |
Loaders |
R310 |
Kubota V1305 26.6HP Dsl |
| 88-On |
KUBOTA |
Misc. Equipment |
D1005 Engine |
All |
| 86-On |
KUBOTA |
Misc. Equipment |
V1200N Engine |
All |
| 05-Bk |
KUBOTA |
Mowers – Front |
F2260-R |
Kubota D1005-EFM 22HP Dsl |
| 89-On |
KUBOTA |
Mowers – Front |
F2400 |
Kubota D1105-FM 24HP Dsl |
| 05-Bk |
KUBOTA |
Mowers – Front |
F2560-E |
Kubota D1105-EFM 25HP Dsl |
| 05-Bk |
KUBOTA |
Mowers – Front |
F2560-R |
Kubota D1105-EFM 25HP Dsl |
| 2006 |
KUBOTA |
Mowers – Front |
F2880 |
Kubota 28HP Diesel |
| 2006 |
KUBOTA |
Mowers – Front |
F2880E |
Kubota 28HP Diesel |
| 05-Bk |
KUBOTA |
Mowers – Front |
F3060-R |
Kubota V1305-FM 30HP Dsl |
| 2006 |
KUBOTA |
Mowers – Front |
F3680 |
Kubota 36HP Diesel |
| All |
KUBOTA |
Mowers – Front |
FZ2100 |
Kubota D905-FZ 21HP Dsl |
| All |
KUBOTA |
Mowers – Front |
FZ2400 |
Kubota D1105-F 24HP Dsl |
| 2001 – 2009 |
KUBOTA |
Tractors – Compact |
B21TL |
Kubota D1005 21HP Dsl |
| 2001 – 2009 |
KUBOTA |
Tractors – Compact |
B21TLB |
Kubota D1005 21HP Dsl |
| 2005 – 2009 |
KUBOTA |
Tractors – Compact |
B26 |
Kubota D1105-E2-UV |
| 96-On |
KUBOTA |
Tractors – Compact |
B7500HSD |
Kubota D1005-E 21HP Dsl |
| 2004 – 2007 |
KUBOTA |
Tractors – Compact |
B7510DT-F |
Kubota D1005-E 21HP Dsl |
| 2004 – 2007 |
KUBOTA |
Tractors – Compact |
B7510DTN-R |
Kubota D1005-E 21HP Dsl |
| 2004 – 2007 |
KUBOTA |
Tractors – Compact |
B7510DT-R |
Kubota D1005-E 21HP Dsl |
| 2004 – 2007 |
KUBOTA |
Tractors – Compact |
B7510HSD-F |
Kubota D1005-E 21HP Dsl |
| 2004 – 2007 |
KUBOTA |
Tractors – Compact |
B7510HSD-R |
Kubota D1005-E 21HP Dsl |
| 2004 – 20075/16/2021 |
KUBOTA |
Tractors – Compact |
B7610HSD-F |
Kubota D1105-E 24HP Dsl |
| 2004 – 20075/16/2021 |
KUBOTA |
Tractors – Compact |
B7610HSD-R |
Kubota D1105-E 24HP Dsl |
| 2005 |
KUBOTA |
Tractors – Garden |
G2160 |
Kubota D782 21HP Dsl |
| 2005 |
KUBOTA |
Tractors – Garden |
G2160-R48S |
Kubota D782 21HP Dsl |
| 2005 |
KUBOTA |
Tractors – Garden |
G2460G |
Kubota WG752 24HP Gas |
| 1998 – 2003 |
KUBOTA |
Tractors – Lawn |
TG1860 |
Kubota D722E-GX 18HP Dsl |
| 1998 – 2003 |
KUBOTA |
Tractors – Lawn |
TG1860G |
WG590V 18HP Gas |
