NEW Alternator for KUBOTA V3300E, V3300 82 & V3300 Tractors – Utility; AMT0118, 400-48089, 1C010-64010, 1C010-64011, 1C010-64012, 3A251-74011, 3C081-74011, 3C081-74012, KEARA1C010; LESTER 12363
$149.99
Specifications
| Unit Type |
Alternator |
| Part Type |
UNIT |
| VOLT |
12 |
| AMPS |
45 |
| REGULATOR CLOCK |
11:00 |
| REGULATOR LOCATION |
Internal |
| FAN LOCATION |
Internal |
| TERMINAL ID 2 |
B+ |
| TERMINAL 2 SIZE |
M6x1.00 |
| TERMINAL ID 3 |
L |
| TERMINAL 3 SIZE |
Spade |
| TERMINAL ID 4 |
R |
| TERMINAL 4 SIZE |
Spade |
| MOUNT HOLE ID 1 |
M8x1.25 |
| MOUNT HOLE 1 TYPE |
Threaded |
| MOUNT HOLE 2 TYPE |
Unthreaded |
| NUMBER OF GROOVES |
1 |
| PULLEY TYPE |
Solid |
| PULLEY OUTER DIAMETER |
2.913″/ 74mm |
| PULLEY TYPE |
Solid |
| POLARITY |
Negative |
WRITE YOUR OWN REVIEW
We appreciate your feedback about our parts, services experience or anything which may help us to serve you better.
[testimonial_view id=”1″]
Part Number & Interchanges
| Manufacturer Name |
Manufacturer Part # |
| ARROWHEAD |
A7TA1677, A7TA3577 |
| KUBOTA |
1C010-64010, 1C010-64011, 1C010-64012, 3A251-74011, 3C081-74011, 3C081-74012, KEARA1C010 |
| LESTER |
12363 |
| MITSUBISHI |
A007TA1677ZC, A7TA1677, A7TA1677ZC, A7TA3577, A7TA3577A, A7TA3577C |
Applications
| YEAR |
MAKE |
MODEL |
ENGINE |
| 1998 – 2005 |
KUBOTA |
M6800 |
Kubota V3300E 68HP Dsl |
| 1998 – 2004 |
KUBOTA |
M6800DT |
Kubota V3300E 68HP Dsl |
| 2001 – 2005 |
KUBOTA |
M6800HD-F |
Kubota V3300E 68HP Dsl |
| 1998 – 2005 |
KUBOTA |
M6800S |
Kubota V3300E 68HP Dsl |
| 1999 – 2004 |
KUBOTA |
M6800SC |
Kubota V3300E 68HP Dsl |
| 2000 – 2004 |
KUBOTA |
M6800SDC |
Kubota V3300E 68HP Dsl |
| 1998 – 2005 |
KUBOTA |
M6800SD-F |
Kubota V3300E 68HP Dsl |
| 1998 – 2005 |
KUBOTA |
M6800SDT |
Kubota V3300E 68HP Dsl |
| 1998 – 2005 |
KUBOTA |
M6800S-F |
Kubota V3300E 68HP Dsl |
| 1998 – 2005 |
KUBOTA |
M8200 |
Kubota V3300 82HP Dsl |
| 1998 – 2005 |
KUBOTA |
M8200C |
Kubota V3300 82HP Dsl |
| 1998 – 2005 |
KUBOTA |
M8200CCS |
Kubota V3300 82HP Dsl |
| 1999 – 2005 |
KUBOTA |
M8200DTC |
Kubota V3300 82HP Dsl |
| 1998 – 2005 |
KUBOTA |
M8200DT-F |
Kubota V3300 82HP Dsl |
| 1998 – 2004 |
KUBOTA |
M8200F |
Kubota V3300 82HP Dsl |
| 2000 – 2005 |
KUBOTA |
M8200SDNB |
Kubota V3300 82HP Dsl |
| 2000 – 2005 |
KUBOTA |
M8200SDNBC |
Kubota V3300 82HP Dsl |
| 2000 – 2005 |
KUBOTA |
M8200SDNBF |
Kubota V3300 82HP Dsl |
| 1999 – 2009 |
KUBOTA |
M9000 |
Kubota V3300 90HP Dsl |
| 1999 – 2009 |
KUBOTA |
M9000C |
Kubota V3300 90HP Dsl |
| 1999 – 2009 |
KUBOTA |
M9000DTC |
Kubota V3300 90HP Dsl |
| 2000 – 2009 |
KUBOTA |
M9000DTCCS |
Kubota V3300 90HP Dsl |
| 1999 – 2009 |
KUBOTA |
M9000DT-F |
Kubota V3300 90HP Dsl |
| 1999 – 2009 |
KUBOTA |
M9000DTL |
Kubota V3300 90HP Dsl |
| 1999 – 2009 |
KUBOTA |
M9000DTL-F |
Kubota V3300 90HP Dsl |
| 2000 – 2009 |
KUBOTA |
M9000DTM |
Kubota V3300 90HP Dsl |
| 2001 – 2009 |
KUBOTA |
M9000DTMC |
Kubota V3300 90HP Dsl |
| 2001 – 2009 |
KUBOTA |
M9000DTMCW |
Kubota V3300 90HP Dsl |
| 2001 – 2009 |
KUBOTA |
M9000DTMW |
Kubota V3300 90HP Dsl |
| 1999 – 2009 |
KUBOTA |
M9000F |
Kubota V3300 90HP Dsl |
