NEW Alternator for MERCEDES BENZ Auto & Light Trucks; 400-24146, 0131543502, 0131545602, 272-154-08-02, A0131545602, A2721540802; LESTER 11220
May 24, 2020NEW Alternator for CASE, CUB CADET & MITSUBISHI Applications; 400-48057, 138008, A0T25171, A0T25271, A0T25371, A0T25471, MM131020, MM432804, MM435081, MM435751, MM435752; LESTER 12231
May 24, 2020New BOSCH Alternator for MERCEDES BENZ Auto & Light Trucks; BOS-AL0844N, 0121715006, 0121715014, 0121715114, 0986047650, 0986047677, AL0844N, AL0844X; LESTER 11220
$999.99
SPECIAL ORDER ELIGIBLE
Product is a Special Order non-stocked item (not eligible for returns). Shipping fees and delivery times may be impacted. Please contact customer service for more information.
Out of stock
Specifications
UNIT TYPE | Alternator |
VOLT | 12 |
AMPS | 180 |
REGULATOR CLOCK | 10:00 |
MOUNT HOLE ID 1 | 9.500mm |
MOUNT HOLE 1 TYPE | Unthreaded |
MOUNT HOLE 2 TYPE | Unthreaded |
MOUNT HOLE ID 3 | 9.500mm |
MOUNT HOLE 3 TYPE | Unthreaded |
FAN LOCATION | Internal |
REGULATOR LOCATION | Internal |
TERMINAL ID 2 | B+ |
TERMINAL 2 SIZE | M8x1.25 |
POLARITY | Negative |
NUMBER OF GROOVES | 6 |
PULLEY TYPE | Solid |
2-Blade Plug |
Part Number & Interchanges
Manufacturer Name | Manufacturer Part # |
ARROWHEAD | ABO0346 |
ARROWHEAD (OEM) | VBO0346 |
ARROWHEAD (OEM) | BAL0844N |
J & N | 400-24297 |
J & N | 400-24146 |
LESTER | 11220 |
BBB | 11220 |
BBB NEW | 11220 |
BOSCH | 0-121-715-114 |
BOSCH | 0-121-715-014 |
DIXIE | A-6536 |
EXCEL | 10925 |
MERCEDES BENZ | 013-154-56-02 |
REMY LIGHT DUTY | 12752 |
USA INDUSTRIES | A3220 |
WILSON | 90-15-6484 |
WILSON | 90-15-6483 |
WILSON NEW | 90-15-6483 |
WORLDWIDE | 12752 |
Part fit
Year | Make | Model | Engine |
---|---|---|---|
Year | Make | Model | Engine |
2006 - 2011 | MERCEDES BENZ | E CLASS | 3.5L |
2007 - 2008 | MERCEDES BENZ | SL CLASS | 5.4L |
2007 - 2009 | MERCEDES BENZ | CLK CLASS | 5.5L |
2007 - 2009 | MERCEDES BENZ | S CLASS | 5.5L |
2007 - 2009 | MERCEDES BENZ | SL CLASS | 5.5L |
2007 - 2010 | MERCEDES BENZ | CL CLASS | 5.5L |
2007 - 2010 | MERCEDES BENZ | R CLASS | 3.5L |
2007 - 2011 | MERCEDES BENZ | CLS CLASS | 5.5L |
2007 - 2011 | MERCEDES BENZ | E CLASS | 5.5L |
2008 - 2010 | MERCEDES BENZ | GL CLASS | 5.5L |
2008 - 2011 | MERCEDES BENZ | ML CLASS | 3.5L |
2008 - 2011 | MERCEDES BENZ | ML CLASS | 5.5L |
2009 | MERCEDES BENZ | G CLASS | 5.4L |
2009 - 2011 | MERCEDES BENZ | SLK CLASS | 3.5L |
2010 - 2011 | MERCEDES BENZ | G CLASS | 5.5L |
2010 - 2011 | MERCEDES BENZ | S CLASS | 5.4L |
2011 | MERCEDES BENZ | SL CLASS | 5.4L |
2012 | MERCEDES-BENZ | SL CLASS | 5.4L |
2012 - 2014 | MERCEDES-BENZ | G CLASS | 5.5L |
