New MAHLE Starter for JOHN DEERE Skid Steer Loaders, Tractors – Farm, Tractors – Utility; MAH-MS293, IS1027, IS1027.3, 028000-8400, 028000-8401, 028000-8402
November 30, 2023
NEW Starter for JOHN DEERE Various Applications; 410-12658, RE19196, RE42730, RE49033, RE51723, RE52119, RE60654, RE64647, TY24305, TY6620; LESTER 6164, 6577
December 1, 2023
NEW Starter for BOBCAT, CLARK Skid Steer Loaders; JOHN DEERE Engines – Marine; 410-52600, RE54092, RE6847, RE68470, 028000-840, 028000-8400, 028000-8401, 028000-8402
$344.99
Specifications
| UNIT TYPE | Starter |
| FAMILY | Denso R |
| QUALITY TYPE | Heavy Duty |
| ELECTRIC STARTER TYPE | Offset Gear Reduction (OSGR) |
| VOLT | 12 |
| POWER | 2.700 kw |
| HP | 3.621 |
| ROTATION DIRECTION | Clockwise |
| NUMBER OF TEETH | 13 |
| GEAR OD | 1.535″ |
| GEAR OD | 39mm |
| MOUNT HOLE ID 1 | 11mm |
| MOUNT HOLE 1 TYPE | Unthreaded |
| MOUNT HOLE 2 TYPE | Unthreaded |
| WARRANTY | 1 Year |
Part Number & Interchanges
| Manufacturer Name | Manufacturer Part # |
| ARROWHEAD | 410-52600 |
| DENSO | 028000-840, 028000-8400, 028000-8401, 028000-8402, 028000-8403, 228000-647, 228000-6470, 228000-6471, 228080-6471, 281-8107 |
| J&N ELECTRICAL PRODUCTS | 410-52049, 410-52056 |
| JLG/GRADALL INDUSTRIES | 91534010 |
| JOHN DEERE | RE54092, RE6847, RE68470 |
