$274.99
SEARCH OTHER VERSIONS: L26025124A, ISKRA 2.8kw DD, ISKRA 3.0kw DD, ISKRA 3.2kw PLGR, MAGNETON OSGR
Specifications
UNIT TYPE | Starter |
FAMILY | Lucas M50 |
ELECTRIC STARTER TYPE | Direct Drive (DD) |
VOLT | 12 |
POWER | 2.800 kw |
HP | 3.755 |
ROTATION DIRECTION | Clockwise |
NUMBER OF TEETH | 10 |
GEAR OD | 1.512″ |
GEAR OD | 38.400mm |
LENGTH | 12.205″ |
LENGTH | 310 mm |
MOUNT HOLE ID 1 | 13.600mm |
MOUNT HOLE 1 TYPE | Unthreaded |
MOUNT HOLE 2 TYPE | Unthreaded |
MOUNT HOLE ID 3 | 13.600mm |
MOUNT HOLE 3 TYPE | Unthreaded |
MOUNTING EAR DISTANCE 1 | 103.400mm |
MOUNTING EAR DISTANCE 1 | 4.071″ |
MOUNTING EAR DISTANCE 2 | 104.700mm |
MOUNTING EAR DISTANCE 2 | 4.122″ |
MOUNTING EAR DISTANCE 3 | 145.700mm |
MOUNTING EAR DISTANCE 3 | 5.736″ |
REGISTRY OD | 3.618″ |
REGISTRY OD | 91.900mm |
WARRANTY | 1 Year |
M8-1.25 B+ Stud, Spade S Terminal Encased In Plastic Housing. |
Part Number & Interchanges
Manufacturer Name | Manufacturer Part # |
ARROWHEAD | IS0632, IS1046, IS1395, L26025124A, MS149, MS206, MS243, SLU0011 |
J&N ELECTRICAL PRODUCTS | 410-30011, 410-30041 |
LESTER | 17653 |
LETRIKA/ISKRA | IS 0632, IS 1046 |
LUCAS ELECTRIC | 26273, 26344, 26365, 26411, 27522, 27540, 27546, 27571, 27582B, 27584, LRS00301 |
LUCAS TVS | 26025124A |
MAHLE | IS1046, IS1395, MS149, MS206, MS243 |
MASSEY FERGUSON | 1691805M1, 1868-283M2, 1868-283-M2, 1868-283-M3, 1868283M5, 3597371M2, 3763363M91, 3763363M94, 579-487-M91 |
PERKINS | 2873B061 |
