NEW Starter for YAMAHA Engine – Marine Outboard; 410-48368, M0TA5071, 6BG81800-00-00
$194.99
Specifications
| UNIT TYPE |
Starter |
| ELECTRIC STARTER TYPE |
Permanent Magnet Gear Reduction (PMGR) |
| ROTATION DIRECTION |
Counter Clockwise |
| VOLT |
12 |
| POWER |
0.900 kw |
| HP |
1.207 |
| NUMBER OF TEETH |
9 |
| GEAR OD |
1.130″ |
| GEAR OD |
28.700mm |
| LENGTH |
159 mm |
| LENGTH |
6.260″ |
| MOUNT HOLE ID 1 |
8.700mm |
| MOUNT HOLE 1 TYPE |
Unthreaded |
| MOUNT HOLE 2 TYPE |
Unthreaded |
| MOUNT HOLE 3 TYPE |
Slotted |
| MOUNTING EAR DISTANCE 1 |
3.020″ |
| MOUNTING EAR DISTANCE 1 |
76.700mm |
| REGISTRY OD |
2.362″ |
| REGISTRY OD |
60mm |
| WARRANTY |
1 Year |
|
(2) 7.1mm ID Unthreaded Holes In Registration Face, DE Housing Mounting Feet 22mm Thick, CE Housing Mounting Foot 24mm Thick, Third Slotted Mounting Hole In CE Housing Mounting Foot, M8 B+ & Motor Studs, M5 Threaded S Tab |
WRITE YOUR OWN REVIEW
We appreciate your feedback about our parts, services experience or anything which may help us to serve you better.
[testimonial_view id=”1″]
Part Number & Interchanges
| Manufacturer Name |
Manufacturer Part # |
| ARROWHEAD |
410-48368, SMT0371 |
| MITSUBISHI |
M0TA5071 |
| YAMAHA |
6BG81800-00-00 |
Applications
| Make |
Model |
Engine |
Years |
| Yamaha |
F25LA |
|
2010 – 2011 |
| Yamaha |
F25LEA |
|
2010 – 2011 |
| Yamaha |
F25LEHA |
|
2010 – 2011 |
| Yamaha |
F25LMHA |
|
2010 – 2011 |
| Yamaha |
F25SEA |
|
2010 – 2011 |
| Yamaha |
F25SEHA |
|
2010 – 2011 |
| Yamaha |
F25SMHA |
|
2010 – 2011 |
| Yamaha |
F40JEA |
|
2009 – 2011 |
| Yamaha |
F40JEHA |
|
2009 – 2011 |
| Yamaha |
F40LA |
|
2009 – 2011 |
| Yamaha |
F40LEHA |
|
2009 – 2011 |
| Yamaha |
T25LA |
|
2010 – 2011 |
