NEW Pump Motor for MONARCH/BUCHER Applications; 430-22051, 8110, 4423720
October 4, 2023
NEW Pump Motor for JS BARNES HYDRAULIC, Monarch & MTE Applications; 430-20028, 46-2107, 46-2369, 46-2414, 46-2585, 46-2595, 46-262, 46-349, 46-717, MDY6101; LESTER 10781, 6033, 6034, 6119
October 6, 2023
NEW Pump Motor for JS BARNES HYDRAULIC, Monarch & MTE Applications; 430-20077, 220-0072, 39200398, 8100, 39200398; LESTER 10786, 10786DBB
$224.99
Various Models
Specifications
| UNIT/PART TYPE | Pump Motor |
| CURRENT TYPE | DC |
| CRITICAL NOTE | Not Supplied With A Bearing Spacer, If The Original Application Used A Bearing Spacer Reuse The Original Spacer |
| VOLT | 12 |
| ROTATION DIRECTION | Counter Clockwise |
| OD | 114.500 mm |
| OD | 4.508″ |
| SHAFT OD | 0.591″ |
| SHAFT OD | 15mm |
| LENGTH | 197 mm |
| LENGTH | 7.756″ |
| TERMINAL 2 SIZE | 5/16/2024 |
| SHAFT | Slotted |
| NUMBER OF FIELDS | 4 |
| WARRANTY | 1 Year |
Part Number & Interchanges
| Manufacturer Name | Manufacturer Part # |
| ARROWHEAD | LPL0040 |
| HALDEX-BARNES | 220-0072, 39200398 |
| J&N ELECTRICAL PRODUCTS | 430-20015, 430-20077 |
| LESTER | 10786, 10786DBB |
| MAXON | 229272 |
| MONARCH/BUCHER | 8100 |
| MTE HYDRAULICS | 39200398 |
| PRESTOLITE | 46-2054, 46-2495, 46-2516, 46-2534, 46-4038, 46-4154, MFX4003, MFX4003S, MMW4001, MMW4002, MMW4002S, MMY4001, MMY4001A, MMY4001S, MMY4004, MMY4004S, MMY6101A, MMY6101AS |
| WALTCO LIFTGATES | 70091739 |
