NEW Winch Motor for SUPERWINCH AND TILT-CAB Applications; 430-22045, SW-801-005C, SW-801-008A, SW-801-008C
$159.99
Specifications
| UNIT | Winch Motor |
| CURRENT TYPE | DC |
| ROTATION DIRECTION | Reversible |
| VOLT | 12 |
| POWER | 1 kw |
| HP | 1.341 |
| OD | 3″ |
| OD | 76.200 mm |
| SHAFT OD | 0.516″ |
| SHAFT OD | 13.100mm |
| LENGTH | 145.500 mm |
| LENGTH | 5.728″ |
| TERMINAL 2 SIZE | M6-1.0 |
| TERMINAL 3 SIZE | M6-1.0 |
| SHAFT | Tang |
| WARRANTY | 1 Year |
Part Number & Interchanges
| Manufacturer Name | Manufacturer Part # |
| ARROWHEAD | SAB0188 |
| J & N | 430-22045 |
| LESTER | 10961 |
| REFERENCE NUMBER | 1113, 1113-A, 19720, 90-33276 |
| SUPER WINCH | SW-801-005C, SW-801-008A, SW-801-008C |
| WESTERN MOTORS | W-8028, W-8028D |
